Reset - RGBlink mini-edge User Manual

mini-edge defaults to T-Bar Mode. Users can also switch to CUT Mode and then use Button 1~5
on the operation board to switch inputs.
For some important occasions, users might need to preview and preset the next scene to ensure
the accuracy and stability of the screen. mini-edge provides T-Bar PVW mode to allow switch after
editing and confirmation.
When PVW Mode is enabled, all operation could be checked on PVW window. Slide T-Bar to
switch between PVW and PGM. Switch time can be customized by sliding the time bar.
Warning:
Only CUT mode supports time setting.

3.14.7 Reset

Select Reset to check current version of mini-edge and perform factory reset.
