In Layer Cropping interface, Width, Height, Horizontal Position and Vertical Position can be set.
Click Reset at the bottom to clear wrong settings so as to restore to the default values.

3.5 Adding Layers

mini-edge allows users to import layers, such as BACKGROUND, LOGO, OVERLAY, etc.

3.5.1 Layer Storage Path

Use a U disk to import layers, such as BACKGROUND, LOGO, OVERLAY, etc.
Before importing layers, please create folders for layer storage in the U disk.
Create Folders Automatically：
1. Insert a U disk into USB interface labeled number 1, reboot mini-edge or enter
BACKGROUND/LOGO/OVERLAY interface.
2. Wait for mini-edge to recognize available files. Figure below indicates no files available in U
disk.
