PR-6000 (Wash 1400W)
PR-2925
The user manual contains important information about the safe installation and use of a projector. Please read and
follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR-6000 and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting PR-6000

Summary of Contents for PR Lighting PR-6000

  • Page 1 PR-6000 (Wash 1400W) PR-2925 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    INDEX 1. SAFETYAND WARNINGS ………………………………………………………………………………………… 2. INSTRUCTIONS …………………………………………………………………………………………………… 3. APPEARANCE ………………………………………………………………………………………………… … 4. INSTALLATION …………………………………………………………………………………………………… 5. SETUPAND CONFIGURATION …………………………………………………………………………………… 6. OPERATIONMENU ………………………………………………………………………………………………… 7. DMX PROTOCOL ………………………………………………………………………………………………… 8. SIGNS ON THE TOUCH SCREEN ………………………………………………………………………………… 9. ERROR MESSAGE……………………………………………………………………………………………… 10. TECHNICAL DATA ……………………………………………………………………………………………… 11.

  • Page 3: Safetyand Warnings

    Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty 1.SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual.

  • Page 4: Instructions

    If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully or by pulling the power cable. ● All power cords must conform to related safety and regulations ● While being operated, the projector should not be under rains or in humidity. ●...

  • Page 5: Appearance

    lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. ●TROUBLESHOOTING PROBLEM ACTION Check the fuse on the power socket.  The projector doesn’t switch on Check the lamp.  The lamp is on but the projector doesn’t respond Make sure that the fixture’s start address is right ...
  • Page 6 Note: 1. the distance between the foot of the base and the front lens cover(the head facing downward) distance between mounting truss and the front lens cover( the head facing downward) 3. The maximum diameter of the rotating head ( minimum spacing between fixtures) Clamp Warning!
  • Page 7 Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. The earth wire(yellow/green) must be connected to the ground. And electrical connection ●...

  • Page 8: Setupand Configuration

    DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 ALIGNMENT/INSTALLATION/REPLACEMENT OFA LAMP ● Before installation/replacement/alignment of a lamp, disconnect the unit from the power and let it cool first. Lock Tilt in the figure below and open the lamp cover after its 4 screws are loosened.
  • Page 9 The projector configuration can be set conveniently via push buttons and color touch screen. To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than 3s(Only ► key to enter the projector ’s function menus. Each powered by the battery, pressing the OK button) to unlock the screen , then press main menu has its sub-menus.

  • Page 10: Operationmenu

    wireless transmitter. STAND-ALONE MODE ● Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE ●...
  • Page 11 Wireless First Wireless In/XLR Out ARTNET Only ARTNET/XLR Out sACN Only sACN In /XLR Out Normal time out Loss of DMX Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config Display Invert Invert ON InvertAuto English Language Setting Chinese Input Password123 Touch Calibration...

  • Page 12: Dmx Protocol

    Boot =XXX System= XXX Driver Board 2 Boot =XXX System= XXX Driver Board 3 Boot =XXX System= XXX Fan Board Boot =XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X Base Fan Ballast Fan Lamp T Fan1 CMY Fan1...
  • Page 13 Close（The lamp’s power changes into 1200W 5 seconds after strobe blades close .） Open Strobe from slow to fast Strobe macros（Strobe at random from fast to slow） Open Dimmer Close Linear dimmer (0-100%) Dimmer in 16 bit Dimmer in 16 bit adjustment CYM macros The following functions will disable CMY, CTO, color wheel1 and color wheel2...
  • Page 14 Color macro30 Color macro31 Color macro32 Color macro33 Color macro34 Color macro35 Color macro36 Color macro37 Color macro38 Color macro39 Color macro40 Color macro41 Color macro42 Color macro43 Color macro44 Color macro45 Color macro46 Color macro47 Color macro48 Color macro49 Color macro50 Color macro51 Color macro52...
  • Page 15 Color macro74 Color macro75 Color macro76 Color macro77 Color macro78 Color macro79 Color macro80 Color macro81 Color macro82 Color macro83 Color macro84 Color macro85 Color macro86 Color macro87 Color macro88 Color macro89 Color macro90 Color macro91 Color macro92 Color macro93 Color macro94 Color macro95 Color macro96...
  • Page 16 White /Color1(Red) Color 1(Red) Color1(Red )/Color2(Yellow) Color2(Yellow) Color2(Yellow)/Color3(Blue) Color3(Blue) Color3(Blue)/Color4(Green) Color4(Green) Color4(Green)/Color5(Pink) Color5(Pink) Color5(Pink)/Color6(Orange) Color6(Orange) Color6(Orange)/ Color7(UV) Color7(UV) Color7(UV)/Open Open Clockwise rainbow effect from slow to fast Anti-clockwise rainbow effect from slow to fast Color wheel1 in 16bit Color wheel 1continuous positioning ,16bit adjustment Color wheel2 Continuous positioning Indexing 0-360°...
  • Page 17 Frost Linear frost 0-100% Focus Linear Focus Focus in 16 bit Focus 16 bit adjustment Zoom Linear Zoom Zoom in 16 bit Zoom 16 bit adjustment Pan movement Pan in 16 bit Pan movement in 16 bit Tilt Tilt movement Tilt in 16 bit Tilt movement in 16 bit Pan &...

  • Page 18: Signs On The Touch Screen

    Zoom Reserved Total reset Reserved Lamp off Reserved Remark: 1. The projector can’t be turned on within 5 minutes after the lamp-off. 2. Fan error can cause lamp-off. 3. "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means both Pan and Tilt will arrive at designated point at the same time.

  • Page 19: Technical Data

    Focus Timeout/magnet Sensor Check if wiring, positioning parts and motors are normal Timeout/magnet Sensor Check if wiring, positioning parts and motors are normal Zoom Lamp Fan1 Error Check if fan and its wiring are normal Check if fan and its wiring are normal Lamp Fan2 Error Head Fan1...
  • Page 20 Orange Yellow Pink Blue Green Color wheel2 Deep Red Light cyan Deep cyan Deep magenta Light Green Light Magenta Light Yellow 0-100% linear CTO ZOOM DMX linear zoom DIMMER 0-100% linear dimmer...
  • Page 21 STROBE Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAMANGLE linear zoom 10°～ 60°with 16 bit function CONTROL DMX512, 5 pin interfaces RDM control protocol 18channels in short mode, 23channels in standard mode and 27channels in extended mode Self-test mode OTHER FUNCTION Adjustable Pan &...
  • Page 22 HOUSING High temperatureABS, IP20 NET WEIGHT 44Kg OPERATION TEMPERATURE °C Ambient temperature at maximum：40 SIZES: LIGHT OUTPUT:...

  • Page 23: Circuitdiagram

    11.CIRCUITDIAGRAM...

  • Page 24: Component Order Codes

    12.COMPONENT ORDER CODES NAME CODE NUMBER REMARKS POWER SWITCH 230020689 POWER FILTER 193020014 THERMAL SWITCH 190010206 ELECTRONIC BALLAST （1400W） 040070140 LAMP （OSRAM 1400W） 100070047 IGNITER (1400W) 040090066 TILT BELT 290151205 PAN BELT 290151207 LAMP FAN 030060117 HEAD FAN 030060119 CHAMBER FAN 030060119 STROBE FAN 030060117...

  • Page 25: Appendix

    Appendix: SOME ITEMS REQUIRING ATTENTION AS FOR THE USE OF DISCHARGE LAMP For the effective extension of the lifespan of discharge lamp, some factors impacting its lifespan are specially listed below, based on manufacturing technology and working mechanism of discharge lamps., physical attributions of the lamps including lamp striking theory( ignited by focused high voltage---highly pressurized air broken down and burning---lamp on at high temperature with thermal protection--- stable running) and lamp off theory( lamp off power ---lamp off at high temperature and thermal protection-highly pressurized air vaporizing evenly----completion of lamp...
  • Page 26 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N: 320021113A...
