AQUA LASER 260 BEAM

PR-8329

The user manual contains important information about the safe installation and use of a projector. Please read

and follow these instructions carefully and keep the manual in a safe place for future reference.

PR LIGHTING LTD.

http://www.pr-lighting.com

Table of Contents

Need help?

Do you have a question about the AQUA LASER 260 BEAM and is the answer not in the manual?

Questions and answers

Summary of Contents for PR Lighting AQUA LASER 260 BEAM

Page 1 AQUA LASER 260 BEAM PR-8329 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
Page 2 Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
Page 3: Safety And Warnings
1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Goggles User Electrical Protective High Warning Flames Manual shock Gloves Temperature ●...
Page 4 ●All power cords must conform to related safety and regulations. ●If a projector is not water and dust proof, while being operated it should not be under rains or in humidity to avoid short circuit. ●Do not switch on and off a projector constantly in very short intervals, otherwise the light source’s and other electrical parts’life will be shortened .
Page 5: Installation
●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature internally causing damages to a projector. Before power-off, please use Tilt channel to move the head and make the head facing downward. Do not use alcohol or other organic solvent to clean the housing to avoid damage.
Page 6 2. The Distance between the top of the feet and the top the head; 3. The head’s rotating diameter( the minimum distance between 2 neighboring projectors on the truss) Warning! For safety, please run the safety cord through its hole. Clamp Safety cord Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to...
Page 7: Setup And Configuration
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX terminator as shown in the figure below.
Page 8 DMX STARTADDRESS ● Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller.
Page 9: Operation Menu
5.OPERATION MENU 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL LEVEL 1-498(Short Mode) Address 1-496(Standard Mode) DMX Address 1-495(Extend Mode) Default IPAddress 2.X.X.X /10.X.X.X IP Address Custom IPAddress X.X.X.X SubNet Mask X.X.X.X ArtNet 0-255 ArtNet Universe sACN universe 1-63999 Really Reset? Total Reset Reset Confirm or Cancel...
Page 10 Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config Display Invert Invert ON InvertAuto English\Chinese Language Setting Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless (Only for fixtures Really Un-Link? with wireless control) Confirm or Cancel Restore Defaults? Factory Defaults Confirm or Cancel Pan DMX Invert...
Page 11 Prism 2 Prism 2 Rotation XXX Focus Tilt ControlFunction XXX Lamp Hous=XXX H Lamp Hours Reset Lamp Hours Total Hours Total Hous ×××× Display Board= ×××C Pan board ×××C Tilt board ×××C Motordriver board1 ×××C Temperature Motordriver board2 ×××C Light source driverboard ×××C Light source= ×××C...
Page 12: Dmx Protocol
Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode? Preset Memory Confirm or Cancel Change Operation Mode? Stand-Alone Mode User Memory 1 Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Change Operation Mode? Static Scene Confirm or Cancel Strobe...
Page 13 071-073 Color2 074-076 Color3 077-079 Color4 080-082 Color5 Color6 083-085 086-088 Color7 089-091 Color8 092-094 Color9 095-097 Color10 098-100 Color11 Color12 101-103 104-106 Color13 107-109 Color14 110-112 Color15 113-115 Color16 116-118 Color17 Color18 119-121 Color19 122-124 125-127 Open 128-191 Rotation ,Clockwise from slow to fast 192-255 Rotation,Anti-clockwise from fast to slow Color Wheel Fine...
Page 14 96-99 Gobo22 100-103 Gobo23 104-107 Gobo24 108-111 Gobo25 Gobo26 112-115 116-119 Gobo27 120-123 Gobo28 124-127 Gobo29 128-149 Clockwise rotation from slow to fast 150-171 Anti Clockwise rotation from slow to fast Shake effect 1 from slow to fast 172-174 175-177 Shake effect 2 from slow to fast 178-180 Shake effect 3 from slow to fast...
Page 15 Stop 193-255 Rotation(Anti- Clockwise from slow to fast) 000-016 White Prism 2 017-127 Prism3 Frost in 128-255 000-127 Indexing Prism2 Stop Prism2 Rotation 129-191 Rotation(Clockwise from slow to fast) Stop 193-255 Rotation(Anti- Clockwise from slow to fast) 000-255 Focus Linear focus 000-255 Focus Fine Focus in 16 bit precision...
Page 16: Error Messages
7. ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Check if wiring, positioning parts and motors are normal Sensor/Encoder Timeout/magnet Check if wiring, positioning parts and motors are normal Tilt Sensor/Encoder...
Page 17 Shakable at variable speeds and bi-directional rotation at variable speeds Prism/frost： 3 prism wheels: (a 8-facet circular prism+ a 4-facet linear prism )+ (a 16-facet circular prism + a frost filter), Other prism options available. Focus DMX linear focus Strobe/dimmer Double flag strobe，0.3-25 F.P.S.
Page 18: Ambient Temperature
Wireless receiver Wireless transmitter ( Optional) ArtNet and sACN ( Optional) Housing and ingress protection Cast aluminum and high temperature and UV resistantABS with IP66 Weight Net weight：37.6Kg Ambient temperature -20 °C ~ 45 °C Note：If a fixture runs with the ambient temperature below 0 Celsius, it should be heated for some time(less than 20 minutes based on actual conditions) before turning on the laser module.
Page 19: Circuit Diagram
9. CIRCUIT DIAGRAM...
Page 20: Component Order Codes
10. COMPONENT ORDER CODES NAME CODE NUMBER 192010237 SWITCHING POWER SUPPLY LIGHT SOURCE 150020339 HEAD FAN 030060116 CHAMBER FAN 030060117 LENS FAN 030060106 LIGHT SOURCE FAN 030060121 BASE FAN 030060075 PAN MOTOR 030040246B TILT MOTOR 030040278B FOCUS MOTOR 030040243A FIXED GOBO MOTOR 030040221C COLOR WHEEL MOTOR 030040221C...
Page 22 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N: 320021423...
