AQUA Laser 500 Beam
PR-8359
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA Laser 500 Beam and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting AQUA Laser 500 Beam

Summary of Contents for PR Lighting AQUA Laser 500 Beam

  • Page 1 AQUA Laser 500 Beam PR-8359 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Goggles User Electrical Protective High Warning Flames Manual shock Gloves Temperature ●...
  • Page 4 ●All power cords must conform to related safety and regulations. ●If a projector is not water and dust proof, while being operated it should not be under rains or in humidity to avoid short circuit. ●Do not switch on and off a projector constantly in very short intervals, otherwise the light source’s and other electrical parts’life will be shortened .

  • Page 5: Installation

    ●Before any maintenance and cleaning, please ensure a project is off the power. ●Only a qualified person is allowed to do maintenance. ●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature internally causing damages to a projector.
  • Page 6 Remarks: 1. The distance between the top of the mounting bar and the top of the head; 2. The Distance between the top of the feet and the top the head; 3. The head’s rotating diameter( the minimum distance between 2 neighboring projectors on the truss) Warning! For safety, please run the safety cord through its hole.
  • Page 7 POWER CONNECTION ● Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. The earth wire(yellow/green) must be connected to the ground.
  • Page 8 DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 4. SETUPAND CONFIGURATION FRONT PANELOPERATION ●...

  • Page 9: Operation Menu

    STAND-ALONE MODE ● Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other.
  • Page 10 Standard Mode 17CH Extended Mode 18CH Ch.01 Strobe Ch.02 Dimmer View Selected Mode … Ch. XX control function Config Settings XLR Only XLR First Wireless Only Wireless First Signal Select (Only for fixtures Wireless In/XLR Out with wireless control) Artnet Only Artnet In/XLR Out sACN only sACN/XLR...
  • Page 11 Settings Tilt DMX Invert OFF/ ON Pan Tilt Swap OFF/ ON XYFeedback OFF/ ON Note: "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means Pan/Tilt mode Speed/Time both Pan and Tilt will arrive at designated point at the same time.
  • Page 12 Lightsourcefanxxx on/off Base fan Lens fan Lamp Fan Error OutSide fan Lightsource fan xxx Channel Value Strobe Dimmer Color Wheel FixedGobo Wheel XXX Manual Effect Prism1 Prism 1 Rotation XXX Service Control Prism 2 Prism 2 Rotation XXX Focus Tilt Factory Mode Change Operation Mode? DMX Mode...

  • Page 13: Dmx Protocol

    Reset User Memory? Reset User Memory 1 Confirm or Cancel Reset User Memory? Reset User Memory 2 Init User Memory Confirm or Cancel Reset Static Scene? Reset Static Scene Confirm or Cancel NOTE: SIGNS OF THE TOUCH SCREEN Config Settings Option Settings Address Information...
  • Page 14 110-112 Color15 113-115 Color16 116-118 Color17 119-121 Color18 Color19 122-124 125-127 Open 128-191 Rotation ,Clockwise from slow to fast 192-255 Rotation,Anti-clockwise from fast to slow Color Wheel Fine 0000-255 Color Wheel in 16 Bit 0-11 Open Gobo1 12-15 16-19 Gobo2 20-23 Gobo3 24-27...
  • Page 15 181-183 Shake effect 4 from slow to fast 184-186 Shake effect 5 from slow to fast 187-189 Shake effect 6 from slow to fast 190-192 Shake effect 7 from slow to fast Shake effect 8 from slow to fast 193-195 196-198 Shake effect 9 from slow to fast 199-201...

  • Page 16: Error Messages

    000-255 Pan(0°~540°) Pan Fine 000-255 Pan in 16 bit Tilt 000-255 Tilt(0°~270°) 000-255 Tilt Fine Tilt in 16 bit Pan & Tilt Speeds 000-255 Pan & Tilt Speed from Fast to Slow 000-019 Reserved Keep in the DMX range for more than 5S to activate the following functions.

  • Page 17: Technical Data

    Timeout Check if wiring, positioning parts and motors are normal Prism Rotation Timeout Check if wiring, positioning parts and motors are normal Focus Check if fan and its wiring are normal Error Pan Board Error Check signal wire Tilt Board Error Check signal wire Motor Driver Board...
  • Page 18 Prism/frost： 3 prism wheels: (an 8-facet circular prism+ a 4-facet linear prism )+ (a 16-facet circular prism + a frost filter), prisms overlapped. Other prism options available. Focus DMX linear focus Strobe/dimmer Double flag strobe，0.3-25 F.P.S. / linear dimmer Movements Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function Beam angle Beam angle：0.8°...

  • Page 19: Circuit Diagram

    Housing and ingress protection Cast aluminum and high temperature and UV resistantABS with IP66 Weight Net weight：39.2 Kg Ambient temperature -20 °C ~ 45 °C Note： If a fixture runs with the ambient temperature below 0 Celsius, it should be heated for some time(less than 20 minutes based on actual conditions) before turning on the laser module.

  • Page 21: Component Order Codes

    10. COMPONENT ORDER CODES NAME CODE NUMBER SWITCHING POWER SUPPLY 192010240 LIGHT SOURCE 150020348 HEAD FAN 030060116 CHAMBER FAN 030060117 LENS FAN 030060106 LIGHT SOURCE FAN 030060121 BASE FAN 030060075 PAN MOTOR 030040246B TILT MOTOR 030040278B FOCUS MOTOR 030040243A FIXED GOBO MOTOR 030040221C COLOR WHEEL MOTOR 030040221C...
  • Page 22 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N: 320021613...
