XRLED 1600-W BWSF

PR-8194

The user manual contains important information about the safe installation and use of a projector. Please read

and follow these instructions carefully and keep the manual in a safe place for future reference.

PR LIGHTING LTD.

http://www.pr-lighting.com

Table of Contents

Need help?

Do you have a question about the XRLED 1600-WBWSF and is the answer not in the manual?

Questions and answers

Summary of Contents for PR Lighting XRLED 1600-WBWSF

Page 1 XRLED 1600-W BWSF PR-8194 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
Page 2: Table Of Contents
Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the...
Page 3: Safetyand Warnings
delivery date but the light source is not within the warranty. 1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Goggles...
Page 4: Instructions
Any electrical connection must be carried out by a qualified person . ● Before installation, please confirm the voltage supplied matches what is required for the projector. ● Each projector must be properly earthed and installed as per related electrical standards. ●...
Page 5: Appearance
To avoid sunlight or other light penetrating into the head via the front lens, resulting in high ● temperature internally causing damages to the projector. Before power-off, please use Tilt channel to move the head and make it facing downward. Do not use alcohol or other organic solvent to clean the housing to avoid damage.
Page 6 Warning Please run the safety cord through its 2 holes for safety Note: 1. the distance between the foot of the base and the front lens cover(the head facing downward) 2. the distance between mounting truss and the front lens cover( the head facing downward) 3.
Page 7 If any questions about the electrical installation, do not continue but consult a qualified electrician. ● DMX CONTROLCONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
Page 8: Setupand Configuration
GOBO REPLACEMENT ● Open the head cover after locking the Tilt and loosening 6 fast-fit screws of the cover and the structures as illustrated by the above figures will be seen. For the rotating gobos: Take out the rotators by hand and remove the spring and gobo. Place a new gobo into the rotator and put back the spring.
Page 9: Dmx Startaddress
FUNC key is for ESCAPE, but ENTER key won’t work, and ENTER key is used for While at 2 and 4 level of menus, the ENTER key to save the changes or enter into the sub menus. Press ▲ or ▼...
Page 10: Operation Menu
After Powered on, the group will run in Master/Slave Mode 6. OPERATION MENU 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL LEVEL 1-473（short mode） 1-467（STD mode） DMX Address 1-454（Extended mode） Default IPAddress 2.X.X.X /10.X.X.X IP Address Custom IPAddress X.X.X.X Address SubNet Mask X.X.X.X ArtNet Universe...
Page 11 XLR Only XLR First Config Settings Wireless Only Wireless First Wireless In/XLR Out ArtNet Only Signal Select ArtNet In/XLR Out sACN Only sACN In /XLR Out Normal time out Loss of DMX Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Invert Invert ON...
Page 12 Pan Tilt Swap OFF/ ON XYFeedback OFF/ ON Pan/Tilt mode Speed/Time Gamma Curve 2.0/2.2/2.4/2.6 1200/2400/4800/10000/12000/15000/2 LED Refresh rate Dimmer Settings 0000/25000Hz Dimmer speed Fast/Medium/Slow Fan Settings Standard/Theatre Moving Head 5-60 Profile 35-60 Profile 15-35 Profile 5-15 Profile 60 Light Type Profile 36 Profile 26 Profile 19...
Page 13 System= XXX Fan Board Boot =XXX Electronic SN XXXXXX XXXXXXX RDM Device Label ANSI E1.20 RDM Power Fan Fan Status Strobe Manual Effect Control Dimmer … … Factory Test Service Change Operation Mode? Confirm/Cancel DMX Mode Change Operation Mode? Preset Memory Confirm/Cancel Change Operation Mode? User Memory 1...
Page 14: Dmx Chart
Operation Mode Reset User Memories 7. DMX CHART Short Standard Extended Decimal Decimal Function mode mode Mode high Strobe Close Pulse strobe speed from slow to fast Strobe from slow to fast Dimmer Close Linear dimming （0-100%） Dimmer Fine Dimmer in 16 bit CMY Macro Disable CMY and CTO before the following functions No function...
Page 15 Color Macro 17 Color Macro 18 Color Macro 19 Color Macro 20 Color Macro 21 Color Macro 22 Color Macro 23 LEE 004 (Medium Bastard Amber) LEE 010 (Medium Yellow) LEE 019 (Fire) LEE 026 (Bright Red) LEE 058 (Lavender) LEE 068 (Sky Blue) LEE 071 (Tokyo Blue) LEE 079 (Just Blue)
Page 16 LEE 152 (Pale Gold) LEE 154 (Pale Rose) LEE 157 (Pink) LEE 158 (Deep Orange) LEE 162 (Bastard Amber) LEE 164 (Flame Red) LEE 165 (Daylight Blue) LEE 169 (Lilac Tint) LEE 170 (Deep Lavender) LEE 172 (Lagoon Blue) LEE 179 (Chrome Orange) LEE 180 (Dark Lavender) LEE 181 (Congo Blue) LEE 197 (Alice Blue)
Page 17 CTO Fine CTO in 16 bit Color Wheel Continual positioning Indexing (0-360degrees) Positioning Open /Color1 (Red) Color1 (Red) Color1 (Red) / Color2( Amber) Color2( Amber) Color2(Amber) / Color3(Blue) Color3( Blue) Color3( Blue) / Color4( Green) Color4(Green) Color4( Green) / Color5(Pink) Color5(Pink) Color5(Pink) / Color6(Yellow) Color6(Yellow)
Page 18 Gobo 4 Rotation （clockwise From slow to Fast） Reverse Rotation（anti-clockwise From slow to Fast） Shake of Gobo 1 from slow to fast Shake of Gobo 2 from slow to fast Shake of Gobo 3 from slow to fast Shake of Gobo 4 from slow to fast Rotating Gobo Wheel Open Gobo1...
Page 19 Framing Blade2left Fine Framing blade 2 left fine control Framing Blade2right Framing blade 2 right 0-100%) Framing Blade2 right Fine Framing blade 2 right fine control Framing Blade3left Framing blade 3 left 0-100% Framing Blade3left Fine Framing blade 3 left fine control Framing Blade3right Framing blade 3 right 0-100% Framing Blade3 right Fine...
Page 20 Effect wheel in Effect wheel rotation from slow to fast Focus Linear Focus Focus Fine Focus in 16 bit precision Zoom Linear Zoom Zoom Fine Zoom in 16 bit precision Autofocus While channels for Iris, Framing module, Fixed gobo wheel and Rotating Gobo Wheel are in use, the fixture has automatic focus function at some distance.
Page 21 High CRI mode Power/Special Function No function Reserved More than 5s in DMX values before the following functions work Graphic Display On Graphic Display Off Reserved Reserved Fan standard mode Fan theater mode Reserved Fast dimmer Medium dimmer Slow dimmer Gamma curve 2.0 Gamma curve 2.2 Gamma curve 2.4...
Page 22 Moving Head 5-60 Profile 35-60 Profile 15-35 Profile 5-15 Profile 60 Profile 36 Profile 26 Profile 19 Profile 10 Profile 5 LED brightness calibration ③ LED brightness 50%-100%, linear calibration LED brightness calibration confirmation Ready to store calibrated value Store calibrated value in the fixture(stay in the DMX range for more than 5s) Remark: Fan error can shut off light source.
Page 23: Error Messages
8. ERROR MESSAGES The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Tilt Timeout...
Page 24: Rotating Gobo Wheel
CRI : Ra ≥70 COLORS CMY color mixing system with macros 1 Color wheel: 7colors+ Open, Half color , bi-directional rainbow effect at variable speeds, Stepping/linear color changing Linear CTO system(0-100%, 1800K-6500K) FRAMING 1 Framing Module: 4 Framing Blades Framing Module continual rotation with many graphics of different sizes and shapes 4 Framing blades to make full curtain effect ROTATING GOBO WHEEL 1 Rotating gobo wheel: 8Rotating Gobos +Open...
Page 25: Effect Wheel
EFFECT WHEEL Bi-directional rotation at variable speeds IRIS 5-100% linear with macros PRISM 1pc, 3-facet circular prism, bi-directional rotation at variable speeds with indexing function FROST 1 frost filter ,0-100% linear BEAMANGLE 5°～60°,linear with 16 bit control FOCUS DMX linear with auto focus function DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds...
Page 26: Ambient Temperature
Brightness calibration function With brightness calibration function to calibrate initial brightness for a single fixture or multiple ones and store brightness values into the fixtures CRI mode Running at high CRI mode via DMX channel to ensure high CRI optical effect. CONTROL International standard DMX512 signal and RDM function 40channels in short mode, 46channels in standard mode,59channel in extended mode...
Page 27: Circuit Diagram
Photometric 10. CIRCUIT DIAGRAM...
Page 29: Component Order Codes
11.COMPONENT ORDER CODES NAME CODE NUMBER REMARK Switching power supply 192010228A Light source 150020355 Power supply fan 030060122 Base fan 030060122 LED driver fan 030060122 Exhuast fan 030060117 Gobo fan 030060117 Inlet fan 1 030060072A Inlet fan 2 030060072A LED Fan 030060142 Pan motor 030040276...
Page 30 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N:...
