Technical Specifications Of The Device; Technical Features - Multitek DIP70Y Installation And User Manual

2.TECHNICAL SPECIFICATIONS OF THE DEVICE

A. TECHNICAL FEATURES
Touch Screen
Camera
CPU
Input
Operating System
Transmission
Codec
Network
Operating voltage&current: 12-18VDC (PoE) ,500mA max
Door release
Operating temperature
Humidity
Installation
Color
Frame lights
Dimensions
Protection
OPTIONAL FEATURES :
LIGHT FRAME
SURFACE MOUNT FRAME : Photocell & surface mount installation
ROTATION APARATUS
RAIN PROTECTOR
: 7" IPS LCD, Resolution 1024x600, LED backlight
: 2.0 Mpixel CMOS, 2.8mm lens,adjustable angle, photo cell, night LEDS
: 1.5GHz, RAM 1GB, FLASH 4 GB
: TF cart , USB, Ethernet
: Android
: TCP/IP ,SIP protocol
: Voice G.711 ,video H.264
: Ethernet (PoE)
: Password, proximity/NFC card
: -20, +70°C (heating pad for lower temperature)
: %20-95 non-condensed
: Flash mount or surface mounth with the frame
: Natural Aluminum
: Photocell, programable to seven colors
: 141x369x14 mm( 172x403x199 mm LED frame)
: IP65, rain, water and dust protected
Screen protected against scratches, vandal proof
: Photocell & seven programable colors
: 30 degrees rotation aparatus
: To protect from the rain
6
