5.5 COMPLIANCE UPLOAD HARDWARE CHECKS

5.5.1 Bluetooth®
1. Confirm that the Bluetooth icon
displayed).
If the icon has a line through it
(section 4.2) to enable the Bluetooth function.
2. Power cycle the device to make it discoverable if you have not just enabled the Bluetooth function (Note: The device only
remains discoverable for a period of 15 minutes after being powered on or after the Bluetooth function is enabled).
3. On a Bluetooth capable mobile device (smartphone, tablet, etc.), confirm that the Bluetooth function is enabled and perform
a Bluetooth scan ensuring you are within approximately 1m of the device.
4. The mobile device should discover the device and display the following: "SleepStyle_xxxx" (where xxxx are the last 4 digits
of the device serial number).
5. On the mobile device, select the device.
6. The mobile device will provide a 6-digit passkey which should also be displayed on the device screen. After confirming that
the passkeys match, pair with the device.

5.5.2 Modem

(Note: Only on applicable models indicated by the modem icon
1. Refer to the Clinician Guide in Appendix D (section 8.6) to perform a manual data upload.
2. If the data upload is successful, the modem is working and the following steps can be skipped.
3. If the upload is unsuccessful, record the result code displayed (Note: the device will attempt to upload for up to 3 minutes).
There are 3 result codes which could indicate a modem problem:
• 012 and 073: these codes indicate a lack of signal strength but this could be due to proximity to the nearest cell site/
tower or if the cellular network is down/experiencing problems. If they occur, check with a known good device before
determining that the device under test is faulty
• 055: this code indicates that there is a problem powering the modem module within the device and is most likely due to
hardware failure
All other result codes indicate that the device has successfully attempted the upload but is not currently registered on the
cellular network. Under these circumstances, the device is considered to be operating correctly unless it has been returned
specifically due to an inability to upload data.

5.5.3 InfoUSB

1. Remove the InfoUSB from the device and plug it into the USB port on a PC.
2. Delete the "FPHCARE" folder (if present) from the InfoUSB.
3. Plug the InfoUSB into the device then press Menu
may flash, this is normal).
4. Wait approx. 2 minutes then remove the InfoUSB and plug it back into the PC USB port.
5. Confirm that the "FPHCARE" folder has been created and that it contains a sub-folder "ICON" in which is another sub-folder
"xxxxxxxx" (where xxxxxxxx are the last 8 digits of the device serial number).
6. Check the fault log for any new error codes (refer to section 5.2).

5.6 DEVICE INSPECTION

The following inspections should be performed to ensure that the device/accessories are in a safe condition and suitable for use:

5.6.1 Power cord

Check the power cord for cuts, stretching, bent pins or excessive wear; replace cord if necessary. Refer to section 5.9 for
replacement power cords.

5.6.2 Enclosure

Check the enclosure for damage or any signs of deliberate alteration; contact your Fisher & Paykel Healthcare representative if
these are observed.

5.6.3 Airpath replaceable parts

Check the condition of the chamber, chamber seal, outlet seal, lid, standard breathing tube/elbow or ThermoSmart breathing
tube and filter; replace where necessary. Refer to section 5.9 for replacement parts.
is displayed on the device screen (Note: Press Menu
, the Bluetooth function is disabled. Refer to the Use and Care Guide in Appendix C
on the front of the device).
and confirm that the InfoUSB icon
if icons are not currently
is displayed (Note: InfoUSB icon
