APPENDIX B: MODEM AND BLUETOOTH WIRELESS TECHNOLOGY
SPECIFICATIONS

MODEM (APPLICABLE MODELS: SPSAAN, SPSCAN, SPSAAU)

Frequency band of Channel
reception Bandwidth
869 to 894 MHz 200kHz
1930 to 1990 MHz 200kHz
1930 to 1990 MHz 5MHz
869 to 894 MHz 5MHz
MODEM (APPLICABLE MODELS: SPSAAA, SPSAAB, SPSAAE, SPSAAJ, SPSAAK,
SPSAAS, SPSAAW, SPSCAA, SPSCAB, SPSCAE, SPSCAK, SPSCAS, SPSCAW)
Frequency band of Channel
reception Bandwidth
869 to 894 MHz 200kHz
925 to 960 MHz 200kHz
1805 to 1880 MHz 200kHz
1930 to 1990 MHz 200kHz
2110 to 2170 MHz 5MHz
1930 to 1990 MHz 5MHz
869 to 894 MHz 5MHz
875 to 885 MHz 5MHz
925 to 960 MHz 5MHz
875 to 890 MHz 5MHz

BLUETOOTH WIRELESS TECHNOLOGY (ALL MODELS)

Frequency band of Channel
reception Bandwidth
2402 to 2480 MHz 1MHz
Frequency band Channel
of transmission Bandwidth
824 to 849 MHz 200kHz
1850 to 1910 MHz 200kHz
1850 to 1910 MHz 5MHz
824 to 849 MHz 5MHz
Frequency band Channel
of transmission Bandwidth
824 to 849 MHz 200kHz
880 to 915 MHz 200kHz
1710 to 1785 MHz 200kHz
1850 to 1910 MHz 200kHz
1920 to 1980 MHz 5MHz
1850 to 1910 MHz 5MHz
824 to 849 MHz 5MHz
830 to 840 MHz 5MHz
880 to 915 MHz 5MHz
830 to 845 MHz 5MHz
Frequency band Channel
of transmission Bandwidth
2402 to 2480 1MHz
MHz
Modulation
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
Modulation
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
GSM – GMSK, GPRS – GMSK,
EDGE – GMSK, 8PSK
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
WCDMA – QPSK, HSDPA – 16-QAM,
HSUPA – QPSK, HSPA+ – 16-QAM,
64QAM
Modulation
GFSK, π/4-DQPSK, 8DPSK
Maximum output power
during transmission
33 dBm ± 2 dB GSM, GPRS
30 dBm ± 2 dB GSM, GPRS
22.5 dBm (± 1.5 dB)
22.5 dBm (± 1.5 dB)
Maximum output power during
transmission
2 Watts - GSM, GPRS and EDGE
2 Watts - GSM, GPRS and EDGE
1 Watt - GSM, GPRS and EDGE
1 Watt - GSM, GPRS and EDGE
23 dBm (+/- 2dBm) Class 3bis
23 dBm (+/- 2dBm) Class 3bis
23 dBm (+/- 2dBm) Class 3bis
23 dBm (+/- 2dBm) Class 3bis
23 dBm (+/- 2dBm) Class 3bis
23 dBm (+/- 2dBm) Class 3bis
Maximum output power
6dBm
