F&P SleepStyle Auto Technical Manual page 35

Use and Care Guide – Page 20
A-20 ENGLISH
The pneumatic flow path:
1 2 3
1. Air inlet filter
2. Ambient temperature sensor
3. Flow sensor
4. Blower
5. Relative humidity sensor
6. Pressure sensor
Humidity output
Tested at 23 °C (73 °F) ambient temperature
Humidity level 7
Humidity level 6
Humidity level 5 (Default)
Humidity level 4
Humidity level 3
Humidity level 2
Humidity Level 1
² AH – Absolute Humidity
3 BTPS – Body Temperature Pressure Saturated
ISO 8185 – Minimum ambient temperature to achieve the ISO 8185 recommended humidity >10 mgH₂O/L BTPS is 12 °C (54 °F)
4
Expiratory Relief
Expiratory relief level
Off
Low
Medium
5 6
7
4
8
9
10
7. Water chamber
8. Heater plate
9. Heater plate temperature sensor
10. Control system
11. Breathing tube
12. Mask
With ThermoSmart breathing tube
12
11
AH (mgH₂O/L BTPS )
2 3
With Standard breathing tube
>23
>21
>18
>17
>15
>13
>10
Pressure reduced during expiration (cmH₂O)
0 cmH₂O
1 cmH₂O
2 cmH₂O
4
>20
>18
>15
>14
>13
>10
>10
F&P SleepStyle Product Technical Guide | 35
