5.7 ELECTRICAL SAFETY TEST

To test for electrical safety, perform the Insulation Resistance test as described below and any other tests required by local regulations.
Note: If any electrical safety tests fail, please contact your Fisher & Paykel Healthcare representative.

5.7.1 Insulation resistance test:

Use a 500 VDC insulation tester to measure the resistance between the mains plug phase and neutral pins (joined together) and
the heater plate - it should be greater than 10 MΩ

5.8 ADDITIONAL INFORMATION

5.8.1 5.8.1

Factory reset:

The factory reset clears all settings and patient data from the device and InfoUSB (Note: If the InfoUSB is not fitted at the time of
factory reset, it will be cleared next time it is put back into the device).
If the device is to be returned directly to the patient, be sure to record all settings as described in section 5.1.1 and upload the
patient data (if required) prior to performing the reset.
To clear the fault log, delete all patient data and restore the device settings back to the factory default values:
Power up the device and enter the Clinician Menu by pressing and holding Start/Stop
1.
buttons together until the menu is displayed.
2. Use Down
3. Use Down
4. The device will perform a power reset and restart with a language screen prompt – power the device down without
changing any settings

5.8.2 Troubleshooting

For troubleshooting information, refer to the Use and Care Guide in Appendix C (section 9) and the Clinician Guide in Appendix
D (section 13).

5.9 REPLACEMENT PARTS

Product code
900SPS100
900SPS101
900SPS111
900SPS110
900SPS120
900SPS121
900SPS122
900SPS140
900SPS141
900SPS142
900SW101
* Applied Parts – to fit 22 mm (0.86 in.) Conical Connector
Product code
900SPS160
900SPS161
900SPS162
900SPS163
900SPS164
900SPS165
900SPS166
900SPS167
Note: Not all replacement parts are available in all countries.
to select "Factory reset" under "SERVICE INFO" then press OK
or Up to select yes
Description
Water chamber
Chamber seal
Air filter (single)
Air filters (2-pack)
ThermoSmart breathing tube*
Standard breathing tube with elbow*
Elbow (for use with a standard breathing
tube)
Device lid
Outlet seal
Carry bag
F&P InfoUSB
Description
Power cord - North America
Power cord - Australasia
Power cord - Europe
Power cord - Brazil
Power cord - Japan
Power cord – United Kingdom
Power cord - China
Power cord – South Korea
and press OK
Applicable models
SPSAAN, SPSCAN, SPSABN, SPSCBN, SPSAAU,
SPSABU
SPSAAA, SPSCAA, SPSABA, SPSCBA
SPSAAE, SPSCAE, SPSABE, SPSCBE, SPSAAW,
SPSCAW, SPSABW, SPSCBW
SPSAAB, SPSCAB, SPSABB, SPSCBB
SPSAAJ, SPSABJ, SPSCBJ
SPSAAK, SPSCAK, SPSABK, SPSCBK
SPSABC, SPSCBC, SPSAFC, SPSCFC
SPSAAS, SPSCAS, SPSABS, SPSCBS
then one of the other device
