Figure 1.3 UPS Rear Panel with Plug-n-Play Battery Connectors
Item
1
2
3
4
5
6
7
8
9
10
11
12

1.3 UPS States and Operating Modes

NOTE: See Table 3.2 on page 44
section.
1 Product Description
Description
Vertiv™Liebert® IntelliSlot™ port
Dry contact port
REPO port
RS-232 port
Multi-function port
Parallel/LBS ports
Ventilation holes
AC output terminals
AC input terminals
Ventilation holes
Battery-connector ports
USB port
, for description of the run indicator and alarm indicator LED's mentioned in this
