Vertiv™ Liebert® ITA2 Installer/User Guide
1.2 Rear Panel Components
Figure 1.2 UPS Rear Panel with Terminal Block Battery Connectors
Item
1
2
3
4
5
6
7
8
9
10
11
12
4
Description
Vertiv™ Liebert® IntelliSlot™ port
Dry contact port
REPO port
RS-232 port
Multi-function port
Parallel/LBS ports
Ventilation holes
AC output terminals
AC input terminals
Ventilation holes
Battery input terminals
USB port
Proprietary and Confidential ©2024 Vertiv Group Corp.
1 Product Description
