  • Page 1 Liebert® ITA2 16kVA&20kVA UPS Quick Start Guide...
  • Page 3 The purchased products, services, and features are stipulated by the contract made between Vertiv Co., and the customer. All or part of the products, services, and features described in this document may not be within the purchasing scope or the usage scope.

  • Page 4: Purpose Of The Document

    Purpose of the Document This document applies to the Liebert® ITA2 UPS which is the next generation series of UPS that provides continuous, high quality AC Power to business critical equipment. This document explains the product description, installation measures, operational workflow, and thorough aspects from the user perspective.

  • Page 5: Version History

    Version History Issue Revision Changes ------- Read this quick start guide carefully before installing and using the Liebert ITA2 16kVA/20kVA UPS (UPS for short) to conveniently install and use this product. For details, refer to Liebert® ITA2 5kVA~20kVA UPS User Manual.
  • Page 6 1 Overview Model Table 1-1 lists the model of the UPS. Table 1-1 UPS models Product Model Power Liebert ITA2 16KVA ITA-16k00AL3A02P00 16000VA/16000W Liebert ITA2 16KVA ITA-16k00AE3A02P00 16000VA/16000W Liebert ITA2 20KVA ITA-20k00AL3A02P00 20000VA/20000W Liebert ITA2 20KVA ITA-20k00AE3A02P00 20000VA/20000W Appearance The front panel of the UPS is shown in Figure 1-1.
  • Page 7 4. Ethernet port 8. USB port 5. Parallel/LBS port 6. AC output port 7. REPO port 9. Multifunction port 10. Battery input port 11. AC input port Figure 1-2 UPS rear panel Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 8: Unpacking Inspection

    2. Check the accessories and models against the delivery list. If any problem is found, please notify the dealer immediately. Mechanical Installation Two installation modes are available: tower installation and rack installation. Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 9: Tower Installation

    3. Place the UPS on the support bases and support base extensions, as shown in Figure 2-3. Support base Battery module (4pcs) Support base Figure 2-3 UPS and battery module installation complete Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 10: Rack Installation

    Use four M6 × 16 screws to fix the UPS in the rack through the brackets, as shown in Figure 2-5. Guide rail Rack Bracket Screw (4pcs) Figure 2-5 Installing the UPS Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 11: Connecting Power Cables

    UPS rear panel. As shown in Figure 1-2. Table 2-1 Shorting copper bar of 16kVA/20kVA Shorting copper bar Drawing 1#: 2PIN copper bar 2#: 3PIN copper bar 3#: 3PIN copper bar Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 12 N N L3 Figure 2-7 Wiring diagram (3-in 3-out, common input configuration) PE sC sB sA N N pC pBpA PE Figure 2-8 Wiring diagram (3-in 3-out, split-bypass configuration) Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 13 AC input upstream and AC output need to configure an MCB of 125A/C. For 3-in 3-out mode, the mains AC input upstream, bypass AC input upstream and AC output need to configure an MCB of 63A/C. See Table 2-2: Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 14 The recommended OT terminals for user external connection are listed below: CSA (unit: mm Terminal type RNBS8-6 RNBS14-6 RNBS22-6 Connection steps 1. Connect the load to the UPS output terminals. 2. Connect the AC input to the UPS input terminals. Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 15: Connecting Battery Cables

    The battery terminals need insulating plates to guarantee the sufficient insulation distance between the battery external cables connection, then avoid the faults like arcing, short circuit occur. See below. Battery insulating plate Figure 2-11 Installing battery insulating plates Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 16 Terminal A BAT+ Second group of battery module BAT N BAT- Cables between battery module and Terminal A 16/20kVA UPS (ITA BCI0020K02L3) Figure 2-12 Cables between UPS and battery modules Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 17 Second block Sixteenth block First block Third block Battery BAT+ module Second block Sixteenth block First block Third block BAT N Battery module BAT- Figure 2-14 Battery string connection principle diagram Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 18: Check Before Start-Up

    Figure 3-1 Operation and display panel When the UPS is the initial start-up, the interface shown in Figure 3-2 will appear to guide the user to set basic parameters of the UPS. Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 19: Welcome Page

    After entering the password, click Next. If the password is correct, then you can enter the guidance interface (2/5). Otherwise the interface shown in Figure 3-2 will appear. Start UP Guidance(1/5) Thanks for using Vertiv UPS Indentify code OE78_82BB_47B9 Password...
  • Page 20 At this page, you can set the battery cell number and total Ah. the 'Battery series' are 24, 32, 40 selectable. No battery module: Start UP Guidance(3/5) Battery series Local battery total AH 18AH Prev Next Figure 3-5 Initial start-up guidance (3) Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 21: Output Page

    Figure 3-8 will appear. Start UP Guidance(4/5) Notify Cannot set this on-line Please unplug REPO e... Prev Next Figure 3-8 Prompt of removing REPO terminal Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 22: Normal Mode Start-Up

    (taking 'Output' as an example). 4. After setting corresponding parameters, press the power button for two seconds, and the LCD prompts a dialogue box shown in Figure 3-10. Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...

  • Page 23: Battery Mode Start-Up

    2. Press the power button for two seconds, the LCD prompts a dialogue box shown in Figure 3-10. After selecting 'YES', the inverter starts, and the run indicator (green) is on. Vertiv | Liebert® ITA2 16kVA&20kVA UPS | Quick Start Guide...
  • Page 24 Vertiv.com | Asia-Pacific © 2017 Vertiv Co. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co.
