Kramer KT-2015 Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
KT-2015:
15" Touch Panel
KT-2015WM:
15" Touch Panel

Step 2: Get to know your KT-2015 / KT-2015WM

# Feature
1 Display
2 Microphone
3 Proximity Sensor
4 Camera
5 Reset
6 Home Button
7 Restore Factory Reset Button
8 USB 3.0 Port
USB Type-C Port
9
LAN 1G(PoE) RJ-45 Port
10
11 Kensington Lock
12 12V/2A DC Connector
KT-2015 Quick Start
KT-2015 / KT-2015WM
This guide helps you install and use your
Go to www.kramerav.com/downloads/KT-2015
upgrades are available.
1 Quick start guide
1 Quick start guide
Function
Touch panel
For audio communication, recording or conferencing.
Automatically adjusts the screen brightness and camera according to the room
lighting conditions.
For future use.
Located on the topside. Insert a pin and hold for a few seconds to restart.
Press to wake up / darken the screen.
Insert a pin and hold for 22 seconds to reset the device to factory default values.
Multipurpose port for external connection.
Multipurpose port for external connection.
Connect to the LAN for network communication.
KT-2015 /
the LAN port.
Optionally, you can connect the power adapter too (as backup).
Anti-theft security slot for locking the device.
Connect to the power adapter (optional, purchased separately).
Quick Start Guide
KT-2015 KT-2015WM
/
to download the latest user manual and check if firmware
Table stand
Wall mount for UK, EU and
USA one gang boxes
KT-2015WM is powered by PoE (power over ethernet) delivered through
P/N: 2900- 301684QS
for the first time.
VESA bracket Mounting accessories
Mounting accessories
Rev: 2
