Scan for full manual
Step 1: Check what's in the box
KT-205WM:
5.5" Touch Panel
Step 2: Get to know your KT-205WM
#
Feature
1
Home Button
2
Recessed Restart Button
3
Restore Factory Reset Button
4
Micro USB Port
5
12V/1A DC Connector
6
LAN 1G(PoE) RJ-45 Port
7
Display
8
Light Sensor
9
Microphone
Speaker
10
KT-205WM Quick Start
KT-205WM
Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/KT-205WM
firmware upgrades are available.
1 Quick start guide
Function
Press to wake up / darken the screen.
Located on the top-side. Insert a pin and hold for a few seconds to restart.
Insert a pin and hold for 22 seconds to reset the device to factory default values.
For connecting to an adjacent on-wall USB device and for firmware upgrade.
Connect to the power adapter (optional, purchased separately).
Connect to the LAN for network communication.
KT-205WM
is powered by PoE (power over ethernet) delivered through the LAN port.
Optionally, you can connect the power adapter too (as backup).
Touch panel
Automatically adjusts the screen brightness according to the room lighting conditions.
For audio communication, recording or conferencing.
To output the sound.
KT-205WM
for the first time.
to download the latest user manual and check if
Wall mount bracket for UK, US
and EU single gang boxes
P/N:
2900- 301701QS
Mounting accessories
Rev:
3
Advertisement
Table of Contents
Related Manuals for Kramer KT-205WM
Summary of Contents for Kramer KT-205WM
- Page 1 1 Quick start guide KT-205WM: 5.5" Touch Panel Wall mount bracket for UK, US Mounting accessories and EU single gang boxes Step 2: Get to know your KT-205WM Feature Function Home Button Press to wake up / darken the screen. Recessed Restart Button Located on the top-side.
- Page 2 Push the touch panel down, snapping the top holders into place. 5. Insert one M2.5 screw below the touch panel and secure the touch panel to the wall mount bracket. For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/KT-205WM. Using third-party cables may cause damage!
- Page 3 Exit the Kramer Agent: Swipe up from the Kramer logo to display the PIN entry pop-up or click RESET PIN. The default PIN is 9428. The bottom navigation bar will pop-up; Press the circle to access the Home screen.
- Page 4 The Launch Control Interface The touch panel’s link to the Kramer Control interface can also be set up from a laptop browser on the network or from the Brain. For more information see the touch panel’s user manual, in the Resources tab at https://www.kramerav.com/product/KT-205#Tab_Resources...
