Scan for full manual
Step 1: Check what's in the box
KT-205WM:
5.5" Tablet

Step 2: Get to know your KT-205WM

#
Feature
1
Home Button
2
Recessed Restart Button
3
Restore Factory Reset Button
4
Micro USB Port
5
12V/1A DC Connector
6
LAN 1G(PoE) RJ-45 Port
7
Display
8
Light Sensor
9
Microphone
Speaker
10
KT-205WM Quick Start
KT-205WM
Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/KT-205WM
firmware upgrades are available.
1 Quick start guide
Function
Press to wake up / darken the screen.
Located on the top-side. Insert a pin and hold for a few seconds to restart.
Insert a pin and hold for 22 seconds to reset the device to factory default values.
For connecting to an adjacent on-wall USB device and for firmware upgrade.
Connect to the power adapter (optional, purchased separately).
Connect to the LAN for network communication.
KT-205WM
is powered by PoE (power over ethernet) delivered through the LAN port.
Optionally, you can connect the power adapter too (as backup).
Touch panel
Automatically adjusts the screen brightness according to the room lighting conditions.
For audio communication, recording or conferencing.
To output the sound.
KT-205WM
for the first time.
to download the latest user manual and check if
Wall mount bracket for UK, US
and EU single gang boxes
P/N: 2 9 0 0 - 3 0 1 6 6 5 QS
Mounting accessories
Rev: 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KT-205WM and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer KT-205WM

  • Page 1 1 Quick start guide KT-205WM: 5.5" Tablet Wall mount bracket for UK, US Mounting accessories and EU single gang boxes Step 2: Get to know your KT-205WM Feature Function Home Button Press to wake up / darken the screen. Recessed Restart Button Located on the top-side.
  • Page 2 Push the tablet down, snapping the top holders into place. 5. Insert one M2.5 screw below the tablet and secure the tablet to the wall mount bracket. For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/KT-205WM. Using third-party cables may cause damage!
  • Page 3 Recommendations for safe exposure to non-ionizing radiation: Only use the device at least 20 centimeters away from your body. Step 5: Customize KT-205WM settings The tablet is designed to operate with Kramer Control. Kramer Control provides an interface which controls all aspects of the meeting space. For more information about Kramer Control, see https://www.kramerav.com/product/Kramer%20Control...
  • Page 4 5. Setup the Kramer Control agent: KT-205WM is designed to operate with Kramer Control. There are two ways to setup the link to Kramer Control: from the tablet or from a laptop. For more information see https://www.manula.com/manuals/kramer/kramer-control/1/en/topic/new-kramer-tablets • Setting the link from the tablet: In the tablet’s Home page, open the Chromium browser...
