- Page 1 USER MANUAL MODEL: KT-208 / KT-208WM 8" Touch Panel P/N: 2900-301633 Rev 1 www.kramerav.com...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Contents Introduction Getting Started Overview Typical Applications Defining KT-208 / KT-208WM 8" Touch Panel KT-208 Tabletop Mount KT-208WM On-Wall Mount Mounting the KT-208 / KT-208WM Mounting KT-208 on a Table Mounting KT-208WM on a Wall Connecting Options... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we have... -
Page 4: Overview
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/quality/environment. -
Page 5: Typical Applications
Typical Applications KT-208 / KT-208WM is ideal for the following typical applications: • Control user interface in meeting and conference rooms, boardrooms, and auditoriums. • Presentation of room scheduling. KT-208 / KT-208WM – Contents... -
Page 6: Defining Kt-208 / Kt-208Wm 8" Touch Panel
Kramer Electronics Ltd. Defining KT-208 / KT-208WM 8" Touch Panel This section defines KT-208 / KT-208WM. Figure 1: KT-208 / KT-208WM 8" Touch Panel Feature Function Display Touch panel Microphone For audio communication, recording or conferencing. Recessed Restart Button Located on the top-side. Insert a pin and hold for a few seconds to restart. -
Page 7: Kt-208 Tabletop Mount
M2.5 screw. M3.2 Screw Opening For securing the wall mount bracket to the gang box. M3.2 Screw Opening For securing the wall mount bracket to the gang box. KT-208 / KT-208WM – Contents... -
Page 8: Mounting The Kt-208 / Kt-208Wm
1. Run any cables that connect to the KT-208 through the center of the table stand (for example the Ethernet cable). 2. Connect the cables to the KT-208. 3. Lay the KT-208 face-down and mount the table stand on it. - Page 9 2. Connect any necessary cables to the KT-208. 3. Mount the KT-208 on the stand. 4. Secure the KT-208 to the stand using the provided M2.5 screw. The table stand and tablet are now ready for use. KT-208 / KT-208WM – Contents...
-
Page 10: Mounting Kt-208Wm On A Wall
5. Insert the M2.5 screw below the tablet and secure the tablet to the wall mount bracket. KT-208 / KT-208WM – Contents... -
Page 11: Connecting Options
Kramer Electronics Ltd. Connecting Options You can power the KT-208 or KT-208WM using any or all of the following options: 1. Connect the PoE-enabled LAN RJ-45 connector to your local area PoE-enabled network. 2. Connect the power adapter to the 12V DC connector on the rear side. The DC power supply is optional: It can be purchased separately. -
Page 12: Essential Kt-208 / Kt-208Wm Settings
17. By default this is set to midnight, change it if you have no internet access at this time or prefer another time. 4. Consider changing the time that the system checks for Kramer Control (APK) updates; Changing the Automated Kramer Control update on page 19. -
Page 13: Controlling Kt-208 / Kt-208Wm
Controlling KT-208 / KT-208WM Using Navigation Buttons or Gestures By default, KT-208 / KT-208WM run the Kramer Control app and displays its login screen at start- up. Log into Kramer Control to access the customizable interface set-up defined by your IT department. -
Page 14: Using The Home Page
To adjust the date and time settings: . The device’s Settings menu opens. 1. On the Home page, press the Settings button 2. Select Date & Time > Time zone. 3. Set the correct Region. The time will display correctly. KT-208 / KT-208WM – Contents... -
Page 15: Connecting To Wi-Fi Or Ethernet
5. Select a Wi-Fi SSID. 6. Check Advanced options and enter the Wi-Fi information in the fields that appear, then press Connect. 7. If you are using 802.1X authentication, then add the certificate information. 802.1X is enabled. KT-208 / KT-208WM – Contents... -
Page 16: Installing An 802.1X Certificate
To browse to the file location, press the 3 lines at the top left of the screen. After installing the certificates, see Connecting to Wi-Fi or Ethernet on page for instructions on using the certificates. Ethernet must be disabled before setting-up Ethernet certificates. KT-208 / KT-208WM – Contents... -
Page 17: Changing The Automated Firmware Update
4. To change the time that the system checks for updates, press Set check time and select a new time. 5. Press OK to close the window and then press SET. Changing (or clearing) the URL will disable the updates. KT-208 / KT-208WM – Contents... - Page 18 PoE or the optional power adapter (see Defining KT-208 / KT-208WM 8" Touch Panel on page 6). To upgrade the firmware 1. Download the firmware update file from the Kramer website at https://www.kramerav.com/product/KT-208#Tab_Resources. ▪ Verify that you are using the correct KT-208 / KT-208WM firmware file as there maybe more than one firmware file available.
-
Page 19: Changing The Automated Kramer Control Update
Kramer Electronics Ltd. Changing the Automated Kramer Control update KT-208 KT-208WM arrive preset to check for Kramer APK (Android Application Package) updates at midnight every day. If an update is found, the device will download the update file and install it. -
Page 20: Connecting The Tablet To Kramer Control
To use Kramer Control, a connection between the tablet and the Kramer Control server must be setup. The Kramer Control connection can be configured either on the tablet itself, or by using a laptop connected to the same network as the tablet (see also https://www.manula.com/manuals/kramer/kramer-control/1/en/topic/new-kramer-tablets) -
Page 21: Scheduling A Daily Reboot
Insert a pin into the pinhole on the back (see Defining KT-208 / KT-208WM 8" Touch Panel on page 6) and hold for 22 seconds to reset the device to factory default values. A second pinhole on the top, can be used to restart the device by inserting a pin for a few seconds. -
Page 22: Logging Activity
Choose between 0 degrees (default), 90 degrees, 180 degrees and 270 degrees. Hiding the navigation bar 1. From the Home page, open the Settings screen 2. In the Settings menu, open Player settings and enable Fullscreen mode. The Navigation bar is no longer accessible. KT-208 / KT-208WM – Contents... -
Page 23: Defining An Auto-Start Playlist
The Content field in the Home page will be changed to the storage location of your content. The home page’s Content field defines the auto-start link to Kramer Control. Changing the value in this field is not recommended as it will disable Kramer Control. Defining auto-start HTML or SMIL content The device home page can be set to automatically run an HTML page or SMIL content. -
Page 24: Switching To Native Android Mode
Switching to native Android mode turns the device into a regular android device, allowing you full control of its content. Changing to native Android will disable Kramer Control. To make the switch: 1. From the Home page, open the Settings screen 2. -
Page 25: Technical Specifications
Tablet 482g Tabletop Stand 300g Shipping carton Dimensions (W,D,H) 290 x 206 x 164mm (4 pcs) Weight KT-208: 1.35kg (includes tabletop stand) KT-208WM: 1kg Accessories Optional Power adapter. KT-208 Tabletop mount unit. KT-208WM On-wall mount unit and panel mount plate Specifications are subject to change without notice at www.kramerav.com... - Page 26 This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
- Page 27 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
