Scan for full manual
Step 1: Check what's in the box
KT-208:
8" Touch Panel
KT-208WM:
8" Touch Panel
Step 2: Get to know your KT-208 / KT-208WM
#
Feature
1
Display
2
Microphone
3
Recessed Restart Button
4
Home Button
5
Camera
6
Light Sensor
7
Speakers
LAN 1G(PoE) RJ-45 Port
8
12V/1A DC Connector
9
10
Restore Factory Reset Button
11
Micro USB Port
KT-208 and KT-208WM Quick Start
KT-208
/
KT-208WM
This guide helps you install and use your
Go to
www.kramerav.com/downloads/KT-208
the latest user manual and check if firmware upgrades are available.
1 Quick start guide
1 Quick start guide
Function
Touch panel
For audio communication, recording or conferencing.
Located on the top-side. Insert a pin and hold for a few seconds to restart.
Press to wake up / darken the screen.
For remote room viewing or video conferencing.
Automatically adjusts the screen brightness and camera according to the room
lighting conditions.
To output the sound.
Connect to the LAN for network communication.
KT-208
and
through the LAN port.
Optionally, you can connect the power adapter too (as backup).
Connect to the power adapter (optional, purchased separately).
Insert a pin and hold for 22 seconds to reset the device to factory default values.
For connecting to an adjacent on-wall USB device and for firmware upgrade.
Quick Start Guide
KT-208
/
KT-208WM
or
www.kramerav.com/downloads/KT-208WM
Table stand
Wall mount bracket for UK, US
and EU single gang boxes
KT-208WM
are powered by PoE (power over ethernet) delivered
P/N:
2900- 301700QS
for the first time.
Mounting accessories
Mounting accessories
Rev:
to download
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kramer KT-208
Summary of Contents for Kramer KT-208
- Page 1 KT-208WM: 8" Touch Panel 1 Quick start guide Wall mount bracket for UK, US Mounting accessories and EU single gang boxes Step 2: Get to know your KT-208 / KT-208WM Feature Function Display Touch panel Microphone For audio communication, recording or conferencing.
- Page 2 4. Secure the to the stand using the provided M2.5 screw. The table stand and touch panel are now ready for use. www.kramerav.com/product/KT-208 For optimum range and performance use the recommended Kramer cables available at Using third-party cables may cause damage!
- Page 3 5. Insert the M2.5 screw below the tablet and secure the touch panel to the wall mount bracket. For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/KT-208WM. Using third-party cables may cause damage! Step 5: Connect to power KT-208 and KT-208WM are powered by PoE (Power over Ethernet).
- Page 4 By default, KT 208 / KT 208WM displays the Kramer Agent interface that turns the touch panel into a controllable device interacting with Kramer Brain / Virtual Brain room control software. The Brain IP needs to be setup (see step 6).
