Kramer KT-208 Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
KT-208:
8" Tablet
KT-208WM:
8" Tablet

Step 2: Get to know your KT-208 / KT-208WM

# Feature
1 Display
2 Microphone
3 Recessed Restart Button
4 Home Button
5 Camera
6 Light Sensor
7 Speakers
LAN 1G(PoE) RJ-45 Port
8
12V/1A DC Connector
9
10 Restore Factory Reset Button
11 Micro USB Port
KT-208 and KT-208WM Quick Start
KT-208 / KT-208WM
This guide helps you install and use your
Go to www.kramerav.com/downloads/KT-208
the latest user manual and check if firmware upgrades are available.
Table stand
Wall mount bracket
Function
Touch panel
For audio communication, recording or conferencing.
Located on the top-side. Insert a pin and hold for a few seconds to restart.
Press to wake up / darken the screen.
For remote room viewing or video conferencing.
Automatically adjusts the screen brightness and camera according to the room
lighting conditions.
To output the sound.
Connect to the LAN for network communication.
KT-208 and
through the LAN port.
Optionally, you can connect the power adapter too (as backup).
Connect to the power adapter (optional, purchased separately).
Insert a pin and hold for 22 seconds to reset the device to factory default values.
For connecting to an adjacent on-wall USB device and for firmware upgrade.
Quick Start Guide
KT-208 / KT-208WM
or www.kramerav.com/downloads/KT-208WM
1 Quick start guide
1 Quick start guide
KT-208WM are powered by PoE (power over ethernet) delivered
P/N: 2 9 0 0 - 3 0 1 6 3 6 QS
for the first time.
2 5/32" screws
2 M3.2 screws
Rev: 3
to download
1 M2.5 screw
1 M2.5 screw
