Christie H Series User Manual
Warping and blending
Hide thumbs
Also See for H Series:
- Service manual (92 pages) ,
- User manual (15 pages) ,
- Quick start manual (2 pages)
Related Manuals for Christie H Series
Summary of Contents for Christie H Series
- Page 1 User Guide 020-000807-03 H Series, HS Series, GS Series and Inspire Series Warping and Blending...
- Page 2 Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose.
-
Page 3: Table Of Contents
Images do not match up..........13 H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. -
Page 4: Installing The Blending And Warping Application
Hardware requirements Learn what hardware is required for the Blending and Warping application. • Computer H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright © 2024 Christie Digital Systems USA, Inc. All rights reserved. -
Page 5: Software Requirements
5. Extract the zip file to a location on the computer. 6. To install the software, double-click the msi file and install the software. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 6: Setting Up The Network Environment
6. Select OK. 7. To close the Local Area Connection Properties, select OK. 8. To close the Local Area Connection Status, select Close. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 7: Warping And Blending
When warping and blending more than two projectors, to having a better visualization shutter for the projectors not being adjusted. 1. Switch to the Warp tab. 2. In the Blank area, select Enable. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 8: Deleting A Projector
1. Make any adjustments required for warping, edge blending, or black leveling, or modify the general settings. 2. From the File menu, select Save. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 9: Opening Previously Saved Settings
6. To change the color of the start marker of the blending area, select the Start color box and select a color. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 10: Adjusting Black Level Blending
In the Color Palette dialog, select the color and select OK. You can store up to ten color settings. Each color setting can be used repeatedly on different selected area. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright ©... -
Page 11: Warping An Image
To increase or decrease the grid number, use the Grid Number slider. You can also use Ctrl+ or Ctrl-. Start with a minimal number of grids and gradually increase the number of grids. Christie recommends starting with a 2x2 setup. Using fewer grids allows for less warping. - Page 12 Warping and blending 6. To revert to the previous warp table, select Reset. 7. Save the file. H Series, HS Series, GS Series and Inspire Series User Guide–Warping and Blending 020-000807-03 Rev. 1 (01-2024) Copyright © 2024 Christie Digital Systems USA, Inc. All rights reserved.
-
Page 13: Troubleshooting
In the projector on-screen display (OSD), make sure the Picture Setting is set to Blending mode. • In the Christie Manual AP software, on the Edge Blending tab make sure the specific locations are set to Enable (left, top, bottom, or right). •...
