  • Page 1 User Manual 020-001792-01 Christie GS Series DWU6322-GS/DWU7062-GS...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.

  • Page 3: Table Of Contents

    DWU6322-GS Series ........
  • Page 4 Rotating the Christie badge ........
  • Page 5 On-screen display tree ......... . . 74 DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 6: Introduction

    Safety and warning guidelines This projector must be operated in an environment that meets the operating range specification. Use only the attachments and/or accessories recommended by Christie. Use of others may result in the risk of fire, shock, or personal injury.

  • Page 7: Ac/Power Precautions

    Caution! If not avoided, the following could result in minor or moderate injury. • ELECTRICAL and BURN HAZARD! Use caution when accessing internal components. • Only Christie qualified technicians are authorized to use the tools provided in the toolbox. Laser safety precautions This projector has been classified as Class 1 Laser Product - Risk Group 2 according to IEC 60825- 1:2014, IEC 62471:2006, and IEC 62471-5:2015 standard.

  • Page 8: Product Labels

    Learn about the labels that may be used on the product. Labels on your product may be yellow or black and white. General hazards Hazard warnings also apply to accessories once they are installed in a Christie product that is connected to power. Fire and Shock Hazard To prevent fire or shock hazards, do not expose this product to rain or moisture.
  • Page 9 This projector has been classified as Class 1 Laser Product- Risk Group 2 according to IEC 60825-1:2014, IEC 62471:2006, and IEC 62471-5:2015. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 10: Projector Components

    Protects the lens motors and mechanism. Remove in order to insert or remove the lens. Adjustable feet Raises or lowers the feet to level the projector. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 11: Rear View

    Connects to the supplied power adapter (100-240V~). Power button Powers the projector on or off. Kensington Security Slot Secures the projector to help prevent theft or unauthorized removal. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 12: Left View

    Built-in keypad Controls the projector. Cooling air vents Provides cooling to the projector. Keep these vents unobstructed to prevent (exhaust) the projector from overheating. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 13: Built-In Keypad

    Returns to the previous level or exits the menus if at top level. Input Selects an input for the main or PIP/PBP image. Picture mute Displays or blanks the video image. Zoom Adjusts the zoom. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 14: Input/Output (I/O) Panel

    RS-232 VGA OUT Connector name Connector name HDBaseT 3D SYNC OUT HDMI-1 REMOTE IN HDMI-2 ETHERNET (LAN) DVI-D RS-232 VGA IN VGA OUT DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 15: Dwu7062-Gs Series

    Connector name Connector name HDBaseT ETHERNET (LAN) HDMI-1 3D SYNC IN HDMI-2 3D SYNC OUT DVI-D RS-232 VGA IN VGA OUT REMOTE IN DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 16: Ir Remote Keypad

    Turns the projector on. GAMMA Adjusts the mid-range levels. BRIGHT Adjusts the amount of light in the image. PIP/PBP Turns PIP/PBP on or off. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 17 Displays the source image information. LENS H Adjusts the position of the image horizontally. LENS V Adjusts the position of the image vertically. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 18: Led Status Indicators

    LED status Projector state Green (solid) Light is on and an image is displayed. Orange (solid) Light is on and the image is blank. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 19: Installation

    Connector name Connector name Connector name HDMI cable RS-232 cable Power cord DVI-D cable 3D sync out cable VGA in cable VGA out cable DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 20: Dwu7062-Gs Series

    • This diagram is for illustrative purposes only, and does not indicate that these accessories are supplied with the projector. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 21: Connecting To Video Equipment

    • This diagram is for illustrative purposes only, and does not indicate that these accessories are supplied with the projector. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 22: Dwu7062-Gs Series

    • This diagram is for illustrative purposes only, and does not indicate that these accessories are supplied with the projector. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 23: Turning The Projector On

    Input Key The first time the projector is used, select the preferred language from the Main Menu after the startup screen is displayed. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 24: Turning The Projector Off

    • Lens 1.52~2.92 (WU) • Lens 2.90~5.50 (WU) • Lens 0.36 (120” screen, WU) • 360 degree operation (along the widest axis) 360° DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 25: Calculating The Lens Offset

    WUXGA projectors The following show vertical and horizontal image offsets for the WUXGA projectors: • Vertical image offset: 0% Lens center DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 26 Installation • Vertical image offset: +100% Lens center • Vertical image offset: -100% Lens center DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 27 Installation • Horizontal image offset: +/-30% -30% +30% DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 28: Removing And Installing The Lens

    6. To install the new lens, fully insert the lens assembly straight into the lens mount without turning. Rotate the lens cap clockwise to lock the lens in place. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 29: Installing The Cable Cover

    Guide Pin Guide Hole Hold and Press Here Installing the ceiling mount Mount the projector with a Christie-approved mount, using the four mounting points on the underside of the projector. List of components on page 70. 1. Refer to the installation instructions and safety guidelines provided in the kit.

  • Page 30: Rotating The Christie Badge

    Installation Rotating the Christie badge The Christie magnetic badge on the front panel of the projector can be rotated for inverted installation. 1. Push on the edge of the badge to release it from its slot on the front panel.

  • Page 31: Operation

    You can then select the next item that you want to adjust in the menu and adjust it. 4. To exit menus if at top level, press EXIT. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 32: Picture Menu

    Gamma Video White Peaking Color Temperature Bright Color Wheel Speed HSG Adjustment Contrast Enhancement Color Space Auto Save to User Select Enter Exit DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 33 • 3x color wheel and the DMD. The higher the speed, the less rainbow effect on the screen. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 34 • Green Gain • Blue Gain • Red Offset • Green Offset • Blue Offset • Color Temperature • Gamma • Detail • White Peaking DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 35: Hsg Adjustment

    A positive hue input provides a counter-clockwise rotation of the color's hue. • A zero input does not change the hue of the color. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 36 A gain of 127 is the nominal setting. • White provides three gain level controls, one each for the R,G,B component of white. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 37: Image Blending

    Blending regions can be defined on all sides left, right, top, and bottom. The same gamma curve is — used for all blending regions. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 38: Screen Menu

    Pixel phase can adjust the phase of the pixel-sampling clock relative to the incoming signal. (Analog RGB signals only.) DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 39 4-corner control by using the on-screen display. • PC Mode on—User can do arbitrary warping or blending control by using PC APP provided separately. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 40 For the 4:3 input sources not recognized by Wide mode (for example, 1400 x 1050), perform Auto Image using Normal mode. Source Info Displays the current source settings. (Read- only). DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 41: Geometry Correction

    This is intended when for use with vertically on- axis applications. Ind. 1080P WUXGA 4.40% 3.41% 8.93% 5.46% DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 42: Pip/Pbp Settings Menu

    Refer to PIP/PBP layout and size on page 44. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 43 Swap Changes the main image to PIP/PBP, and the — PIP/PBP to main image. Swapping is available only when PIP/PBP is enabled. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 44: Pip/Pbp Layout And Size

    Medium Large PIP-Bottom Right PIP-Bottom Left PIP-Top Left PIP-Top Right PBP Size PBP Layout Small Medium Large PBP, Main Left PBP, Main Right DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 45: Settings Menu

    • English for the on-screen display. • Simplified Chinese • French • German • Italian • Japanese • Korean • Russian • Spanish DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 46 • Error Log—Shows the projector error log for debug. • Laser Diode Info—Displays the information of each laser diode bank including its voltage, current, and temperature. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 47: Language Menu

    Choose the required internal test pattern to display, or select None to turn off a test pattern. Test Pattern None Grid White Black Checkerboard Color Bars DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 48: Light Source Menu

    Displays the total hours of the projector, the — Info total hours of the laser diode that have been used, and information on the light sensor calibration. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 49: Options Menu

    If an active signal is received before the projector powers down, the image is displayed. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 50 • Off Backlight Controls the backlight • Keypad Backlight Preferences behavior and status LED. • Status LED Information Displays the projector — settings. (Read-only) DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 51: Information Menu

    PIP/PBP Vert Refresh Light Source Power Light Source Hours Standby Mode Communication mode Lens Lock Settings Allow IP Address DHCP System Temperature Exit DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 52 PIP/PBP Vert Refresh Light Source Power Light Source Hours Standby Mode Communication mode Lens Lock Settings Allow IP Address DHCP System Temperature Exit DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 53: 3D Menu

    3D@120Hz. • Side-by-Side(Half) • Top and Bottom • Frame Sequential (DWU7062-GS only) 1080p@24 Sets the 3D resolution 1080p@24 frequency. • 96Hz • 144Hz DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 54: Communications Menu

    The Communications menu sets the LAN parameters, network status, and other settings for the projector. Communications Network Serial Port Baud Rate Serial Port Echo Serial Port Path Select Enter Exit DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 55 Controls whether the serial port echoes • Off characters. • On Serial Port Path Sets the serial port path to RS232 or • RS232 HDBaseT. • HDBaseT DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 56: Lan Settings

    • Microsoft Edge 40 • Firefox 57 • Chrome 63 • Safari 11 • Operating system of mobile devices • iOS 10 • Android 5 DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 57: Logging On To The Web User Interface

    5. In the Username field, type the username. The default username is admin. 6. In the Password field, type the password. The default password is admin. 7. Click Login. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 58: Setting The System Notification

    SNMP Trap and Email—Send the notification to the trap receiver and the email • recipient. 4. To apply the notification settings, click Save. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 59: Troubleshooting

    7. If the projector is still not projecting the entire image, change the monitor display: a. Verify the resolution setting is lower than or equal to WUXGA (1920 × 1200). b. Switch to the Monitor tab. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 60: Presentation Is Not Displayed

    Some Notebook PCs may deactivate their own screens when a second display device is in use. Each has a different method of reactivation. Resolution Refer to your computer manual for information on changing the method of reactivation. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 61: Unstable Or Flickering Images

    When you play anamorphic DVD or 16:9 DVD, the projector shows the best image if the projector display mode is set to 16:9 in the on-screen display. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 62: Image Is Not The Correct Size

    Contact your IT engineer if the steps above cannot resolve the network issue. • Turning off DHCP returns back to default setting if DHCP on fails. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 63: Connection Fail With New Ip Address

    Make sure every device has a unique IP address. • Contact your network engineer if the steps above cannot resolve the network issue. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 64: Specifications

    Specifications Learn about the product specifications. Due to continuing research, specifications are subject to change without notice. Inputs The following table details the inputs for GS Series. RB in the Resolution column indicates reduced blanking. Signal Type Resolution Frame rate (Hz)
  • Page 65 ● ● ● 1280x800 ● ● ● 1280x800 ● ● ● 1280x960 ● ● ● 1280x960 ● ● ● 1280x960 ● ● ● DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 66 ● 1864x1050 ● 1864x1050 ● 1920X1080 ● 1920X1080 ● ● ● 1920X1200RB ● ● ● 1920X1200RB ● ● ● NTSC NTSC (M, 4.43) DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 67 ● ● ● 1080p ● ● ● 1080p ● ● ● 1080p ● ● ● 1080p ● ● ● 1080p ● ● ● DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 68: Pip/Pbp Compatibility

    ● ● ● HDMI-1 ● ● HDBaseT ● ● • Dot (●): PIP/PBP combinations are enabled. • Dash (-): PIP/PBP combinations are disabled. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 69: Key Features

    (Ethernet or RS232) • A Web page via Ethernet • Weight: • Maximum product weight (with lens removed): 16.5 kg (36 lbs) • Built-In keypad DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 70: List Of Components

    Shipping without lens (includes packaging) 22.3 kg (49.2 lbs) Operating position 360 degree front to back and portrait capable Free orientation and no tilt range constraint. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 71: Physical Operating Environment

    Maximum power consumption, ECO mode Input 470W Maximum power consumption, WLAN mode Input < 8.0W Maximum power consumption, Standby mode Input < 0.5W DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 72: Regulatory

    China Ministry of Information Industry Order No.39 (02/2006) on the control of pollution caused by electronic information products, the hazardous substances concentration limits (SJ/T11363-2006), and the applicable product marking requirement (SJ/T11364-2006). DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 73: Marking

    It is essential that only the supplied power cord be used. • Use only shielded signal cables to connect I/O devices to this equipment. DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.

  • Page 74: On-Screen Display Tree

    (white color). Video Film Depend on Gamma Bright color mode. DICOM White Peaking 0 ~ 100 Warm Color Bright Bright Temperature Cool DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 75 0 ~ 199 Blue 1 ~ 199 Reset to Default Contrast Dynamic Black Enhancement Real Black Auto RGB(0-255) Color Space Auto RGB(16-235) Save to User DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 76 Top Right Vert Correction Adjust 4 Corners Bottom Left Horz Adjust Bottom Left Vert Adjust Bottom Right Horz Adjust Bottom Right Vert Adjust DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 77 Bottom Left Bottom Right Small Size Medium Medium Large Swap Change Sources Input key List all Sources Auto Source Normal Auto Image Wide Wide DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 78 Left Top Left Bottom Right Bottom 0.5W mode LAN (Standby) Communication Communication mode None Grid White Test Pattern None Black Checkerboard Color Bars DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 79 10 mins ) Focus Command Options Zoom Command Lens Shift Command Lens settings Allow Lock Lens Allow Motors Locked Lens Calibration High Altitude DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 80 DDP FW M9813 FW Information Motor FW PW808 FW Main Input Main Signal Format Main Pixel Clock Main Sync Type Main Horz Refresh DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 81 3D Format AVINFO data Top and Bottom existed then display 3D Frame mode Sequential automatically. 96Hz 1080p @ 24 144Hz 144Hz DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 82 2400 4800 9600 Serial Port Baud 14400 115200 Rate 19200 38400 57600 115200 Serial Port Echo RS232 Serial Port Path RS232 HDBaseT DWU6322-GS/DWU7062-GS User Manual 020-001792-01 Rev. 1 (04-2020) Copyright ©2020 Christie Digital Systems USA Inc. All rights reserved.
  • Page 83 Corporate of ces Worldwide of ces Christie Digital Systems USA, Inc. Australia Germany Republic of South Africa United Kingdom Cypress ph: +61 (0) 7 3624 4888 ph: +49 2161 664540 ph: +27 (0)11 510 0094 ph: +44 (0) 118 977 8000...
