4.2.

ADDITIONAL CONTACTS

The function allows users enter additional contacts. First of all, it is necessary to register such a contact (1-6 pcs.). To do this,
select the Registration option and briefly press the communication button on the device, e.g. EU-MW-1.
After registering and switching on the device, the following functions will appear:
➢ Information – provides information about the status, operation mode and contact range (displayed on the controller
screen)
➢ ON - enables/disables contact operation
➢ Operation mode – enables activation of the selected contact operation mode
➢ Time mode – allows setting the contact operation time for a specific time
Users can change the contact status by selecting/deselecting the
➢ Constant mode – allows setting the contact to operate permanently; it is possible to change the contact status by
selecting/deselecting the
➢ Relays – the contact works according to the zones to which it has been assigned
➢ Dehumidification – if the
➢ Schedule settings – allows users to set a separate contact operation schedule (regardless of the status of the board zones).
CAUTION
The Dehumidification
➢ Delete – used to delete the selected contact
4.3.

MIXING VALVE

The EU-L-4X WiFi board can operate an additional valve using a valve module (e.g. the EU-i-1m). This valve has RS
communication, but it is necessary to carry out the registration process, which will require users to quote the module number
located in the rear of its housing, or in the software information screen). After correct registration, individual parameters of
the auxiliary valve can be set-up.
➢ Information - allows viewing the valve parameters status.
➢ Register - After entering the code on the back of the valve or in the
the valve with the main controller.
➢ Manual mode – users have the ability to manually stop the valve operation, open/close the valve and switch the
pump on and off in order to control the correct operation of the devices
➢ Version - displays the valve software version number. This information is necessary when contacting the service.
➢ Valve removal - used to completely delete information about a selected valve and its operation from the system.
The function is applied, for example, when removing the valve or replacing the module (it is then necessary to re-
register the new module).
➢ ON – temporarily enables/ disables valve operation
➢ Valve set temperature – for establishing valve set temperature
➢ Summer mode –switching to summer mode closes the valve to avoid unnecessary heating of the house. If the boiler
temperature is too high (enabled boiler protection is required), the valve will be opened in emergency mode. This
mode is not active in
Active option.
Maximum Humidity is exceeded in a zone, this option allows start-up of the air dehumidifier
function operates only in the
Return protection mode.
Active option and then setting
Cooling operation mode.
Menu → Software
18
the Duration of this mode
Information, users can register
