To configure a schedule:
•
Use the arrows
2nd part of week).
•
Use the MENU button to go to the set temperature settings that will apply outside the time intervals - set it with
the arrows, confirm using the MENU button
•
Use the MENU button to go to the settings of the time intervals and the set temperature that will apply to the
specified time interval, set it using the arrows, confirm with the MENU button
•
Proceed to the editing of days that are assigned to the 1st or 2nd part of the week (active days are displayed in
white). The settings are confirmed with the MENU button, the arrows navigate between each day
After setting the schedule for all days of the week, press the EXIT button and select the
CAUTION
Users can set three different time intervals in a given schedule (with an accuracy of 15 minutes).
3.

CONTROLLER SETTINGS

➢ Time settings - the current time and date can be automatically downloaded from the network if the Internet module
is connected and the automatic mode is enabled. It is also possible for users to manually set the time and date if the
automatic mode does not operate correctly.
➢ Screen settings - This function allows users to customize the display.
➢ Sound the buttons - this option is chosen to enable/disable the sound that will accompany pressing the buttons.
4.

FITTER'S MENU

The fitter's menu is the most complex controller menu and enables users to access a wide selection of functions that allow
for maximum use of the controller's capabilities.
4.1.

ZONES

To activate a zone on the controller display, register/activate a sensor therein and then activate the zone.
4.1.1. ROOM SENSOR
Users can register/enable any type of sensor: NTC wired, RS or wireless.
➢ Hysteresis - adds a tolerance for the room temperature in the range of 0.1 ÷ 5°C, at which there is additional
heating/cooling enabled.
Example:
The preset room temperature is 23°C
Hysteresis is 1°C
The room sensor will start to indicate room underheating after the temperature drops to 22°C.
to select the part of the week for which the set schedule will apply (1st part of the week or
Confirm
13
option with the MENU button.
