4.4.

INTERNET MODULE

The Internet module is a device that allows remote control of the installation. Users can control the operation of various
devices and change some parameters via the
The device has a built-in Internet module. After switching on the Internet module and selecting the DHCP option, the
controller will automatically retrieve through the local network the parameters of: IP address, IP mask, Gateway address and
DNS address.
In order for the Internet module to operate correctly, it is required to connect the module to a network with a DHCP server
and an open port 2000.
Once the Internet module is properly connected to the network, go to the module settings menu (in the master controller).
If the network does not have a DHCP server, the Internet module must be configured by its administrator by entering the
appropriate parameters (DHCP, IP Address, Gateway Address, Subnet Mask, DNS Address).
1. Go to the settings menu of the Internet module.
2. Select the "ON" option
3. Then check if the "DHCP" option is checked.
4. Enter "WIFI Selection"
5. Then select the WIFI network and enter its password.
6. Wait for a moment (ca. 1min) and check if the IP address has been assigned. Go to the "IP Address" tab and check if
the value is different than 0.0.0.0/ -.-.-.- .
a. If the value still indicates 0.0.0.0 / -.-.-.-.- , check the network settings or the Ethernet connection between the
Internet module and the device.
7. After correctly assigning the IP address, register the module to generate the code that is required to assign it to an
application account.
4.5.

MANUAL MODE

This function allows users to control the operation of individual devices. Users can manually switch on each of the devices:
pump, potential-free contact and individual valve actuators. It is recommended to use manual mode to check the correct
operation of the connected devices at the first start-up.
4.6.

EXTERNAL SENSOR

CAUTION
This function is only available when a EU-C-8zr external sensor has been registered in the EU-L-4X WiFi board.
Registering the external sensor allows users to switch on the weather control.
➢ Sensor selection – to select a wireless EU-C-8zr sensor that requires registration.
➢ Calibration - The calibration is performed at installation or after prolonged use of the sensor if the temperature
measured by the sensor deviates from the actual temperature. Adjustment range is from -10°C to +10°C with a step
of 0.1°C.
In the case of a registered wireless sensor, the subsequent parameters relate to the range and level of the battery.
4.7.

HEATING STOPPING

Function to prevent actuators from turning on at specified time intervals.
➢ Date settings
•
Heating deactivation – To set the date from which the heating will be switched off
•
Heating activation – To set the date from which the heating will be switched on
➢
-
Weather control
while the controller menu will display the mean external temperature.
emodul.eu
Required network settings
When the external sensor is connected, the main screen will display the external temperature,
application.
