Summary of Contents for Siemens SIMATIC NET RUGGEDCOM RP100
- Page 1 Edition 10/2023 Equipment Manual SIMATIC NET Rugged Ethernet switches RUGGEDCOM RP100 https://www.siemens.com/ruggedcom...
- Page 2 Preface Introduction Installing the Device SIMATIC NET Device Management Rugged Ethernet switches RUGGEDCOM RP100 Communication Ports Technical Specifications Equipment Manual Certification 10/2023 C79000-G8976-1011-07...
- Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 4: Table Of Contents
SIMATIC NET glossary ......................vi Registered trademarks ......................vi Warranty ..........................vii Training ..........................vii Customer support ......................... viii Contacting Siemens ......................viii Introduction ........................... 1 Description ......................2 Required Tools and Materials ................. 3 Decommissioning and disposal ................3 Installing the Device ...................... - Page 5 Table of contents 6.1.2 European_Union ....................21 6.1.3 TÜV SÜD ......................22 6.1.4 FCC ........................22 6.1.5 ISED ........................22 6.1.6 ISO ........................23 6.1.7 ACMA ........................23 6.1.8 RoHS ........................23 EMC and Environmental Type Tests ..............24 RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
-
Page 6: Preface
Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer's exposure to cyber threats. -
Page 7: Supplementary Documentation
SIMATIC NET glossary The SIMATIC NET glossary describes special terms that may be used in this document. The glossary is available online via Siemens Industry Online Support (SIOS) at: https://support.industry.siemens.com/cs/ww/en/view/50305045 Registered trademarks The following and possibly other names not identified by the registered trademark sign ®... -
Page 8: Warranty
Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. -
Page 9: Customer Support
Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit https://w3.siemens.com/aspa_app/?lang=en. Mobile app Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile device and be able to: •... -
Page 10: Introduction
Introduction The RUGGEDCOM RP100 provides the flexibility to power remote PoE (Power over Ethernet) devices using standard shielded CAT 5 cables. Converging data and power onto a single cable saves money, space and labor for new and existing installations. Compatible with the latest 802.3at high power PoE standard and backwards compatible with low power 802.3af PoE devices, the RP100 provides versatility and investment protection to handle future demands for increased power. -
Page 11: Description
Introduction 1.1 Description Key Features • Substation Rated: • IEC 61850-3 • IEEE 1613 • -40 to 85 °C (-40 to 185 °F) operating (no fans) • Industrial Design: • Panel or DIN mounting • Lightweight Cast Aluminum Enclosure • Performance: •... -
Page 12: Required Tools And Materials
WEEE directive 2012/19/EU for the disposal of electrical and electronic equipment. Do not dispose of devices at public disposal sites. For environmentally friendly recycling and the disposal of devices, contact a certified disposal company for electronic scrap or your Siemens contact. For more information, refer to https://support.industry.siemens.com/cs/ww/en/ view/109479891. - Page 13 Introduction 1.3 Decommissioning and disposal RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
-
Page 14: Installing The Device
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens Canada Ltd. could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment. -
Page 15: General Procedure
Installing the Device 2.1 General Procedure NOTICE This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken. Access must only be possible through the use of a tool, lock and key, or other means of security, and controlled by the authority responsible for the location. -
Page 16: Mounting The Device
Visually inspect each item in the package for any physical damage. Verify all items are included. Note If any item is missing or damaged, contact Siemens for assistance. Mounting the Device The RUGGEDCOM RP100 can be ordered with a DIN rail adapter pre-installed on the back of the chassis. - Page 17 Installing the Device 2.3 Mounting the Device DIN Rail DIN Rail Adapter Figure 2.1 Mounting the Device to a DIN Rail Insert a flathead screw driver into the slot of the sliding release and move it down. Push the device against the bottom of the DIN rail, then let go of the sliding release to latch the device.
-
Page 18: Installing The Device Outdoors
62368-1. The clamping voltage must also be less than 60 V and the protector must not activate when the voltage is less than 56 V. For more information, contact Siemens Customer Support. NOTICE Install the lightning protector and RP100 as close as possible. -
Page 19: Grounding The Device
Installing the Device 2.5 Grounding the Device CPE/PD Shielded Cable Ground Connection Lightning Protector RP100 Drain Wire (Shielded) Figure 2.3 Typical Outdoor Installation Grounding the Device The RP100 chassis ground terminal uses a #6-32 screw. It is recommended to terminate the ground connection with a #6 ring tongue and torque the screw to 8.3 N·m (6 lbf·in). -
Page 20: Connecting Ac Power
Installing the Device 2.6.1 Connecting AC Power Note • For 100-240 VAC rated equipment, an appropriately rated AC circuit breaker must be installed. • For 125-250 VDC rated equipment, an appropriately rated DC circuit breaker must be installed. • Use minimum #16 gage copper wiring when connecting terminal blocks. •... -
Page 21: 2.6.2 Connecting Dc Power
Installing the Device 2.6.2 Connecting DC Power Surge Ground Terminal Braided Ground Cable Figure 2.5 Terminal Block Wiring Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block. Using a braided wire or other appropriate grounding wire, connect the surge ground terminal to the chassis ground connection. - Page 22 Installing the Device 2.6.2 Connecting DC Power Braided Ground Cable Figure 2.6 Terminal Block Wiring Connect the negative wire from the power source to the negative/neutral (-/N) terminal on the terminal block. Using a braided wire or other appropriate grounding wire, connect the surge ground terminal to the chassis ground connection.
- Page 23 Installing the Device 2.6.2 Connecting DC Power RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
-
Page 24: Device Management
Device Management This section describes how to connect to and manage the device. Connecting a RUGGEDCOM WIN Subscriber Station The RUGGEDCOM RP100 is designed to be a Power-over-Ethernet (POE) injector for RUGGEDCOM WIN5000 series subscriber stations. NOTICE If the RUGGEDCOM RP100 is to be installed outdoors, make sure the connection between both devices is bridged by a suitably rated lightening protector. - Page 25 Device Management 3.1 Connecting a RUGGEDCOM WIN Subscriber Station RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
-
Page 26: Communication Ports
Communication Ports The RP100 supports a copper 10/100Base-TX Ethernet port and a 10/100Base-TX PoE (Power over Ethernet) Ethernet port, both with RJ45 connectors. The RJ45 connectors are directly connected to the chassis ground on the device and can accept CAT-5 shielded twisted-pair (STP) cables. The PoE port injects power on pins 4, 5, 7 and 8. - Page 27 Communication Ports Signal Non-PoE Terminated Terminated Case Shield (Chassis Ground) RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
-
Page 28: Technical Specifications
Technical Specifications This section provides important technical specifications related to the device. General specifications Insulation Class I Overvoltage category OVC II Power Supply Specifications Rated Input Rated Output Power Voltage Current 12 VDC 3.5 A 52 VDC (PoE), 25 W, @ 85 °C (185 °F) 24 VDC 52 VDC (PoE), 32 W, @ 85 °C (185 °F) -
Page 29: Dimension Drawings
Technical Specifications 5.5 Dimension Drawings Enclosure Diecast Aluminum Dimension Drawings Note All dimensions are in millimeters, unless otherwise stated. 77.2 56.6 11.4 95.0 Figure 5.1 Overall Dimensions RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07... -
Page 30: Certification
Assessed (UKCA) marking. The marking is printed on the body of the device. 6.1.2 European_Union This device is declared by Siemens Canada Ltd. to comply with essential requirements and other relevant provisions of the following EU directives: • EN 62368-1 Information Technology Equipment –... -
Page 31: 6.1.3 Tüv Süd
6.1.5 ISED This device is declared by Siemens Canada Ltd. to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) -
Page 32: Iso
Support at https://support.industry.siemens.com/cs/ww/en/view/89855782. 6.1.8 RoHS This device is declared by Siemens Canada Ltd. to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: •... -
Page 33: Emc And Environmental Type Tests
Certification 6.2 EMC and Environmental Type Tests EMC and Environmental Type Tests The RUGGEDCOM RP100 has passed the following EMC and environmental tests. IEC 61850-3 Type Tests Test Description Test Levels Severity Levels Enclosure ± 8 kV 61000-4-2 Contact Enclosure Air ±... - Page 34 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels Ripple on DC Power Supply DC Power 61000-4-17 Ports Dielectric Strength DC Power 1.5 kVDC 60255-27 Ports AC Power 2 kVDC Ports HV Impulse DC Power 5 kV ...
- Page 35 Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels IEC 60068-2-2 Dry Heat Test Bd 85 °C (185 °F), 16 Hours IEC 60068-2-6 Vibration 2 g @ 10-150 Hz Class 2 IEC 60068-2-27 Shock 30 g @ 11 ms Class 2 RUGGEDCOM RP100 Equipment Manual, 10/2023, C79000-G8976-1011-07...
- Page 36 For more information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens Canada Ltd. Digital Industries Process Automation 300 Applewood Crescent Concord, Ontario, L4K 4E5 Canada © 2023 Siemens Canada Ltd. Subject to change...
