4.
5.
Electrocution hazard – risk of death, serious personal injury, and/or damage to
the device
Make sure the supplied safety cover is always installed before the device is powered.
RUGGEDCOM RST2228
Equipment Manual, 10/2023, C79000-G8976-1359-19
Note
For examples of various wiring combinations, refer to "Wiring
examples" (Page 32).
Reinsert the terminal block plug into the device.
For European-style (Euroblock) terminal block plugs, use a slotted screwdriver to
tighten the captive screws.
1
European-style (Euroblock) terminal block plug
1
Screw-type terminal block plug
2
Figure 2.13 Assembling the power supply terminal block plug
Install the safety cover.
DANGER
1
2
Safety cover
1
Screw
2
Figure 2.14 Installing the safety cover
Installing the device
2.5.2 Connecting main power
2
31
