Wiring Diagram - Directed DS3+ Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Comfort System Module
(black/white conn.
in left rear quarter panel,
below fuse box)
1
17
(+) Brake:
Black/Red, pin 12
32 16
Remove the battery from
Cut
the OEM remote control.
• Position 6-8 loops on top of
the key, not around it.
• Test and secure mounted loops
before reassembling vehicle.
6 933.POR02EU 1.01.193.2 2019 Porsche Cayenne (Smart Key) EU
©2023 Directed. All rights
Comfort System Module
(blue/white conn. in left rear
quarter panel, below fuse box)
17
CUT
(-) Ignition Control:
Yellow/Gray, pin 25
(-) Accessory:
White/Gray, pin 26
32
Immo. Antenna:
White, pin 1
1
Comfort System Module
(black conn. in left rear quarter
panel, below fuse box)
HS CAN 1 Low:
1
Orange/Brown, pin 1
HS CAN 1 High:
Green, pin 2
(-) Starter:
Blue/Yellow, pin 10
(-) Ignition:
Red/Gray, pin 11
16
(-) Ignition Output: Blue/White: 2
(-) Accessory Output: Red/White: 4
(+) Brake Activation Output: Violet/Black: 8
(-) Starter Output: Blue/Black: 9
(+) Siren Output: Brown/Red: 11
Hood Pin
Siren
Ignition Control Interrupt (conn. side): Blue/White: 1
Ignition Control Interrupt (veh. side): Blue: 3
(+) 12V:
(-) Ground:
Brown, pin 15 Red/Yellow, pin 16
1 2 3 4 5 6 7
15 16 17
8 9 10 11 12 13 14
Comfort System Module
(green conn.
in left rear quarter panel,
below fuse box)
Comfort System Module
(in left rear quarter panel, below fuse box)
HS CAN 1 Low: Tan: 1
HS CAN 1 High: Tan/Black: 2
A module can also be used for
this installation.
(-) Hood Input: Gray: 21
IMPORTANT:
Position the
Key Wrap: Lt. Green/Red: 7
fuses correctly!
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
Slide to open
(+) 12V Input: Red: 6 & 12
Legend:
).
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
