Directed DS3+ Installation Manual page 10

Module
Conn./Pin Color Description
H4/6 Green No Connection
H4/7 Violet No Connection
H4/8 Orange No Connection
H4/9 Red/White No Connection
H4/10 Pink No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
10 933.POR02EU 1.01.193.2 2019 Porsche Cayenne (Smart Key) EU
©2023 Directed. All rights
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-) Wire Color
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
(+/-) Wire Color
Connection
Connection
Mandatory
Mandatory
