When Used In Conjunction With Smartstart; D2D Port Configuration - Directed DS3+ Installation Manual

before providing power to the Directed SmartStart
SmartStart with Loops – The brown loop must be cut.
SmartStart with Pigtails – The gray wire must be connected to a ground source.
Loops
DO NOT connect the Directed SmartStart
D2D connector on the module. Refer to the Directed SmartStart

D2D port configuration

Caution! Do not connect the Control Center (antenna) or any digital sensors (8504D) to the white D2D1 port.
The white D2D1 port is reserved ONLY for SmartStart, Module flashing or 3rd Party bypass. The two black D2D2 ports are reserved for the
Control Center (antenna) and digital sensors (8504D).
