Wiring Diagram - Directed Directechs DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Junction Block
Driver's Fuse/Junction Block
front view
(white connector front of fuse box)
15 14 13
C-204
7 6 5
(-) Driver Door Trigger:
Lt. Green, pin 6
D2D Port
(-) Ground
(-) Trunk Release Output
(-) Unock Output
(-) Lock Output
(-) Hood Input
(AC) Tach Input
(+) Parking Lights Output
(+) Accessory 2 Output
(+) Ignition Output
(+) 12V Input
(+) Accessory 1 Output
(+) Starter Output
(-) Starter Output
(-) Hood Pin Input
For Manual Transmission ONLY
Relay pin 30
(+) 12V
86
6 403.MIT4 2.07 2012 Mitsubishi Galant
©2022 VOXX•DEI LLC. All rights reserved.
(-) Unlock: Lt.Green/Red, pin 14
11 10 9 8
12
4 3 2 1
(-) Lock: Violet, pin 13
Junction Block
rear view
(-) Hood
Hood Pin
Relay pin 87a
Clutch:
Cut
Brown/Black,
pin 2
87
85
1 2
87a
30
Clutch
Pedal
ETACS-ECU
(white connector, left rear of dash fuse box)
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
19 20 21 22 23 24
(-) Trunk Release:
Black/Yellow, pin 21
Keysense:
Blue/Red,
CUT
pin 10
Keysense Interr. Output (veh. side): Orange/Red: 10
Keysense Interr. Output (conn. side): Yellow/Red: 11
(-) RAP Off Output: Green/Black, pin 2
(AC) Tach Output: Violet/White, pin 5
(+) Ignition: Black/White, pin 2
(+) 12V: Blue/Yellow, pin 1
(+) Accessory 2:
1 2 3
Blue/Black, pin 6
4 5 6
(+) Accessory 1: Blue/Red, pin 4
(+) Starter: Black/Yellow, pin 5
Ignition Switch
(white connector at ignition switch)
OBDII
Diagnostic Connector
HS CAN High: Red, pin 6
1 8
9 16
HS CAN Low: Black, pin 14
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
(+) 12V Input: Brown: 7
(+) Ignition Output: Yellow: 8
Signal Lights
(white connector in dash fuse box)
1 2 3 4 5 6 7
8 9 10 11 12 13
(+) Turn Signal
(left):
6 Amp
Green/Red,
Diodes
pin 8
).
XKD2D65
14 15
(+) Turn Signal
(right):
Green/Yellow,
pin 13
