IMPORTANT SAFETY INFORMATION
WARNING: HAZARDOUS VAPORS
Paints, solvents, insecticides, and other materials
can be harmful if inhaled or come in contact
with the body. Vapors can cause severe nausea,
fainting, or poisoning.
PREVENTION:
•
Use a respirator or mask if vapors can be inhaled. Read all
instructions supplied with the mask to be sure it will provide the
necessary protection.
•
Wear protective eyewear.
•
Wear protective clothing as required by coating manufacturer.
WARNING: GENERAL
Can cause severe injury or property damage.
PREVENTION:
•
Always wear appropriate gloves, eye protection, clothing and a
respirator or mask when painting.
•
Do not operate or spray near children. Keep children away from
equipment at all times.
•
Do not overreach or stand on an unstable support. Keep
effective footing and balance at all times.
•
Stay alert and watch what you are doing.
•
Do not operate the unit when fatigued or under the influence of
drugs or alcohol.
•
Do not kink or over-bend the hose. Airless hose can develop
leaks from wear, kinking and abuse. A leak can inject material
into the skin.
•
Do not expose the hose to temperatures or pressures in excess
of those specified by manufacturer.
•
Do not use the hose as a strength member to pull or lift the
equipment.
•
Use lowest possible pressure to flush equipment.
•
Follow all appropriate local, state and national codes governing
ventilation, fire prevention and operation.
•
The United States Government Safety Standards have been
adopted under the Occupational Safety and Health Act
(OSHA). These standards, particularly part 1910 of the General
Standards and part 1926 of the Construction Standards should
be consulted.
•
Before each use, check all hoses for cuts, leaks, abrasion or
bulging of cover. Check for damage or movement of couplings.
Immediately replace hose if any of those conditions exist. Never
repair a paint hose. Replace with a conductive high-pressure
hose.
•
Do not spray outdoors on windy days.
•
Always unplug cord from outlet before working on equipment
(electric models only).

SPECIFICATIONS

Maximum Pressure
Capacity
Tank Capacity
Horsepower
Max. tip
Power Requirement
Generator power
requirement
Overheating
protection
CAPABILITY
Sprays a variety of paints (oil-based and latex), primers, stains,
preservatives and other nonabrasive materials.
DO NOT USE!
This pump should not be used with textured materials, block filler,
lacquers, industrial enamels, or asphalt sealer or materials containing
HHC. See coating supplier if flash point is not listed on the container.
Do not spray or clean with liquids having a flash point of less than
38ºC (100ºF). Flash point is the temperature at which a fluid can
produce enough vapor to ignite.
SAFETY FEATURES
Spray gun trigger lock and pressure diffuser; built-in tip safety guard;
PRIME/SPRAY knob for safe pressure release. Conforms to UL STD
1450. Certified to CSA C22.2 NO 68.
EN

GENERAL INFORMATION

Control Pro 130 Power Tank
1600 PSI (11.1 MPa)
0.24 GPM (0.91 LPM)
1.5 gallon (5.7 l)
0.38
0.015"
15 amp minimum circuit on 115 VAC,
60 Hz current
2500 Watt (disable idle-down feature)
This sprayer has a built-in protective
device to prevent damage from
overheating. The sprayer may
automatically shut down after heavy
use. If this happens, turn switch OFF
(0), unplug the sprayer and allow to
cool for 20-30 minutes and resume
spraying.
5
