SPRAYING TROUBLESHOOTING - CLEAR THE SPRAY TIP
If the spray pattern becomes distorted or stops
i
spraying completely while the gun is triggered, the
spray tip could be clogged. Follow the steps below.
YOU WILL NEED
•
Scrap material / cardboard
Do not attempt to unclog or clean the tip with your
finger. High pressure fluid can cause injection injury.
1.
Lock the spray gun.
2.
Rotate spray tip 180 degrees from its current position.
If spray tip is difficult to rotate, relieve pressure by:
i
1) slowly turn PRIME/SPRAY knob to PRIME,
2) unlock the spray gun and
3) squeeze trigger while pointing at scrap material/
cardboard.
Release trigger, lock the spray gun, and try rotating
spray tip again.
3.
Make sure the PRIME/SPRAY knob is turned to SPRAY.
Unlock the spray gun.
Point at a piece of scrap material / cardboard and squeeze trigger
until material comes out in a high pressure stream. Release the
trigger and lock the spray gun.
4.
Rotate spray tip forward to the spray position.
Unlock the spray gun and resume spraying.
If tip clogs are persistent, an optional gun filter may
i
be purchased. See Accessories section (page 58) for
optional gun filters.
