LONG TERM STORAGE

Follow these steps to prepare your sprayer for long-
i
term storage.
YOU WILL NEED
•
Light household oil (such as 10W30 motor oil or vegetable oil for
example) / All Guard
•
Rags
•
Two adjustable wrenches
1.
Pull trigger guard from gun housing.
2.
Tighten the wrench over the wrench flats (a). Unscrew the gun
housing using a wrench.
3.
Tip the spray gun upside down and pour a few drops of All Guard
inside the gun housing nut (DO NOT remove the nut).
A penetrating oil like WD40 can be substituted.
Reassemble the spray gun.
4.
Place a wrench on the outlet valve to secure it. Using the second
wrench, remove the spray hose.
5.
Remove the inlet filter. Pour approximately 2 ounces of All Guard
inside the inlet valve housing. A light oil can be substituted (such
as 10W30 motor oil or vegetable oil for example).
6.
Cover the outlet valve with a rag. Turn the power ON (l) and let the
pump run for 5 seconds.
Turn power OFF.
7.
Replace inlet filter. Wipe entire unit, hose, and spray gun to
remove accumulated spray material.
Store the unit indoors with the power cord wrapped
around the base.
