TABLE OF CONTENTS

IMPORTANT SAFETY INFORMATION ___________________ 2-4
Explanation of Symbols ________________________________ 2
Grounding Instructions ________________________________ 3
Important Electrical Information _________________________ 3
Safety Hazards _____________________________________ 3-4
GENERAL INFORMATION _______________________________ 5
Specifications ________________________________________ 5
PARTS AND COMPONENTS _____________________________ 6
Assembly ___________________________________________ 6
BEFORE YOU BEGIN ____________________________________ 7
Locking the Spray Gun _________________________________ 7
Pressure Relief Procedure ______________________________ 7
Moving / Emptying the Sprayer __________________________ 7
LOAD MATERIAL ______________________________________ 8
SPRAYING ____________________________________________ 9
PRACTICE SPRAYING _________________________________ 10
SPRAYING TROUBLESHOOTING _____________________ 11-12
Clear the Spray Tip ___________________________________ 11
Clean the Inlet Filter __________________________________ 12
SHORT TERM STORAGE _______________________________ 13
CLEANUP _________________________________________ 14-15
LONG TERM STORAGE ________________________________ 16
MAINTENANCE ____________________________________ 17-18
Cleaning the Inlet Valve _______________________________ 17
Cleaning the Outlet Valve _____________________________ 18
TROUBLESHOOTING __________________________________ 19
PARTS LIST _______________________________________ 56-58
WARRANTY __________________________________________ 59
2

EXPLANATION OF SYMBOLS

Read all safety information before operating the equipment. Save
these instructions.
To reduce the risks of fire or explosion, electrical shock and the
injury to persons, read and understand all instructions included in
this manual. Be familiar with the controls and proper usage of the
equipment.

This symbol indicates a potential hazard
that may cause serious injury or loss of life.
Important safety information will follow.
 This symbol indicates a potential hazard to you
or to the equipment. Important information
that tells how to prevent damage to the
Attention
equipment or how to avoid causes of minor
injuries will follow.

Danger of skin injection

Danger of fire from solvent and paint fumes
Danger of explosion from solvent, paint fumes

and incompatible materials
Danger of injury from inhalation of harmful

vapors

Electric shock hazard
Notes give important information which
i

should be given special attention.
The Control Pro can only be used with spray
tips, hoses or spray guns that are Control Pro
compatible.
accessories with this system.
EN
Do not use any non-Control Pro
