Clean The Inlet Filter - WAGNER CONTROL PRO 130 POWER TANK Owner's Manual

SPRAYING TROUBLESHOOTING - CLEAN THE INLET FILTER
If the spray pattern becomes distorted or stops
i
spraying completely while the gun is triggered, the
inlet filter could be clogged. Follow the steps below.
YOU WILL NEED
•
Warm, soapy water for latex material
•
Mineral spirits for oil based materials
Make sure your floors and furnishings are covered
with drop cloths to prevent accidental drips.
Attention
1.
Perform the Pressure Relief Procedure, page 7.
2.
Empty the tank of spray material (see Moving / Emptying the
Sprayer, page 7. Do not run the sprayer without spray material or
water in the tank.
3.
Remove inlet filter from tank.
Clean the inlet filter using the appropriate cleaning solution (warm,
soapy water with latex- and water-based materials, mineral spirits
with oil-based paints or stains).
4.
Snap the inlet filter back into place.
Resume spraying (follow steps on pages 8-9)
If the inlet filter clogs, it is a good idea to strain the
i
material you are using prior to filling the hopper.
If after completing all of the steps in Spraying
i
Troubleshooting you are still experiencing problems
spraying, refer to the Troubleshooting section (page
19).
12
1
PAGE 7
2
3
4
EN
k
