Status LED beacons' errors
2 — E S T A T E E R R O R
This means that there has occurred a communication error between the
EV and the Charge Point. If this is the case, the status LED light bar flashes
in a sequence of two blinks.
3 — P R O X I M I T Y E R R O R
When the Charge Point is connected to the EV, a Proximity short-circuit to
earth may occur. The, the status LED light bar turns flashes in a sequence
of three blinks.
4 — N E G A T I V E P W M V O L T A G E E R R O R
When the Charge Point is connected to the EV, the PWM signal, used to
communicate the Charge Point with the EV, can be negative. Then, the
status LED light bar flashes in a sequence of four blinks.
5 — N O N - C U R R E N T S E L E C T I O N E R R O R ( D I P - S W I T C H )
If the on-board current limit selection is not set up according to the
hardware features, the Charge Point detects it and shows this error. In this
case, the status LED light bar flashes in a sequence of six blinks.
2
Blink Sequence
3
Blink Sequence
4
Blink Sequence
6
Blink Sequence
