Wallbox & Post eVolve Smart - User Manual
10
A
DATA GENERAL SPECIFICATIONS
Light beacon
Enclosure rating
Enclosure material
Enclosure door
Net weight
Dimensions (W x H x D)
Socket
Type 2 socket protection
(Optional)
Cable (Optional)
Power supply
Input voltage
Frequency
Operating temperature
Mininum operating temperature
with Low Temperature Kit
(Optional)*
Operating humidity
Overcurrent protection
Residual current protection
(*) Equipment to be installed outdoors shall be provided with the Low Temperature
52 Kit in order to comply with the IEC 61851-1:2017.
Post
RGB Colour indicator
IP54 / IK10
Aluminium & ABS
Frontal key locked door
55 Kg
450 x 1550 x 290 mm
Type 2 + Locking System
Shutter
Type 2
1P+N+PE / 3P+N+PE
230V AC+/- 10% / 400V AC+/-10%
50 Hz / 60 Hz
-5ºC to +50ºC
-30ºC
5% to 95% Non-condensing
Miniature Circuit Breaker (MCB)
IEC 60898-1 (Curve C)
RCD Type A (30 mA) + 6 mA DC /
Type B (Optional)
