DESCRIPTION OF PARTS

8
9
13
11
17
12
1. Table Clamp
3. Swivel Arm locking knob
5. Tension Adjustment Knob
7. Suspension arm hydraulic movement lock
9. Binocular head with eyepieces
11. Magnichanger Locking Knob
13. Carrier Locking Knob
15. Handles
17. Binocular head locking knob
6167500-795
7
10
16
15
Fig. 1
2. Column
4. eVALUX Illumination Box
6. Suspension Arm
8. Illumination Control Knob
10. Magnichanger Knob
12. Common Main Objective
14. Swivel Arm
16. Filter Knob
PRIMA DNT Trainer
PRIMA DNT Trainer
5
6
14
4
3
2
1
