UNPACKING

The appliance is delivered in sub-assembled groups along with one set of Installation Kit and one

instruction / service manual.

Please check following at the time of unpacking:

1. Table Mount

2. Column

3. Swivel arm and Suspension arm assembly with bre optic cable.

4. eVALUX Illumination Box.

5. Inclined coupling with magni-changer assembly and objective (as ordered)

6. Observation Head, (inclined or ergo) as ordered

7. Paired Eye Pieces, as ordered

8. Power Cord

9. Set of sterilizable caps

10. Installation Kit

a) Allen Wrench 5.00mm

b) Allen Wrench 8.00mm

11. Instruction cum Operating Manual / Service Manual

6167500-795

PRIMA DNT Trainer

Issue 1.0

Printed on May,2013
