Adjusting Display Mode

To display images of aspect ratios other than your monitor aspect ratio and sizes other
than your display size, you can adjust the display mode on the monitor.
1. Press the 5-way controller to bring up the hotkey menu, and select
access the main menu.
2. Go to Picture > Advanced > Display Mode.
3. Select an appropriate display mode. The setting will take effect immediately.

Choosing an appropriate color mode

Your monitor provides various color modes that are suitable for different types of images.
See Color Mode on page 59
Go to Color > Color Mode for a desired color mode.
The computer's color profile (ICC profile) may not best suit your monitor. If you want to make sure to obtain
the accurate color matching representation, change the computer's ICC profile to ensure the computer
works better with the monitor. Visit
monitor model for instructions. Alternatively, enable the ICC Sync function from the Display Pilot / Display
Pilot 2 software (page

Working with two video sources (KVM Switch)

If you have two computer systems, you might find yourself busy going back and forth
between two sets of keyboard and mouse to control each display separately. Now with the
KVM feature and sufficient I/O ports on one monitor, you can work with one set of keyboard
and mouse only.
To use KVM Switch feature, toggle between Thunderbolt 3 (models with Thunderbolt™) /
USB-C (models without Thunderbolt™) or USB Upstream under KVM Switch. Available
video inputs and the corresponding menu options vary by model and are not specified in
the following statement. Refer to your monitor OSD menus for available options and
settings.
• KVM Switch > Thunderbolt 3 (models with Thunderbolt™) / USB-C (PD3420Q): Switches
to the Thunderbolt™ 3 / USB-C™ input.
• KVM Switch > USB Upstream: Switches to one of the video inputs other than
Thunderbolt™ 3 (models with Thunderbolt™) / USB-C™ (PD3420Q). With appropriate
setting, the display is switched to the set input while the keyboard and mouse control is
switched as well. To determine the input, see
Switch before use on page
You can designate one of the custom keys to KVM Switch to toggle between the options
quickly. See Customizing the hot keys on page
Setting up the second video source for KVM Switch before
use
If your model came with a KVM pairing label near I/O ports on the rear of the monitor, simply connect the
video sources properly as indicated by the label.
One of the video sources is pre-defined to be transmitted via Thunderbolt™ 3 (models with
Thunderbolt™) / USB-C™ (PD3420Q) and cannot be changed. The other source can come
from other available inputs and should be set appropriately in advance.
for all the available color modes.
Support.BenQ.com
3). Refer to the Display Pilot / Display Pilot 2 manual for details.
46.
to access the
ICC Profile Installation Guide
Setting up the second video source for KVM
42.
46
(Menu) to
under your
