Terminal Connections - M-system R8-NECT1 Operating Manual

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
• UNIT
• PROTECTIVE COVER
50 (1.97) [3 (.12)]
5 (.20)
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
55 (2.17) [4 (.16)]
DIN RAIL
(35 mm wide)
50 (1.97)
EM-9738-B Rev.13 P. 4 / 20
R8-NECT1
