M-system R8-NECT1 Operating Manual page 7

I/O CARD I/O MODULE
R8-PA4F R8-PA4F (ch1)
R8-PA4F (ch2)
R8-PA4F (ch3)
R8-PA4F (ch4)
R8-PC4A R8-PC4A (ch1, ch2)
R8-PC4A (ch3, ch4)
R8-WTUD R8-WTUD(data1,2)
R8-WTUD(data3,4)
:
R8-WTUD(data15,16)
R8-TC2 R8-TC2 (data1, 2)
R8-TC2 (data3, 4)
:
R8-TC2 (data15, 16)
R8-DA4A R8-DA4A
R8-DC4A R8-DC4A
R8-DC4A2 R8-DC4A2
R8-DC4C R8-DC4C
R8-DCT4D R8-DCT4D
R8-DAT8A2 R8-DAT8A2
R8-DAT8B2 R8-DAT8B2
R8-DCT8A2 R8-DCT8A2
R8-DCT8B2 R8-DCT8B2
R8-DAM16A R8-DAM16A
R8-DAT16A2 R8-DAT16x
R8-DAT16B2
R8-DCM16A R8-DCM16A
R8-DCT16A2 R8-DCT16x
R8-DCT16B2
R8-DCM32B2 R8-DCM32B2 (ch1 − 16)
R8-DCM32B2 (ch17 − 32)
R8-DCM16ALZ R8-DCM16ALZ
R8-DCM16ALK R8-DCM16ALK
R8-DCM16ALH R8-DCM16ALH
MODULE TYPE
Pulse input
Pulse input
Pulse input
Pulse input
Pulse output
Pulse output
Data input
Data input
:
Data input
Data I/O
Data I/O
:
Data I/O
Discrete input, 4 points
Discrete output, 4 points
Discrete output, 4 points
Discrete output, 4 points
Discrete output, 4 points
Discrete input, 8 points
Discrete input, 8 points
Discrete output, 8 points
Discrete output, 8 points
Discrete input, 16 points
Discrete input, 16 points
Discrete output, 16 points
Discrete output, 16 points
Discrete output, 16 points
Discrete output, 16 points
Discrete output, 16 points, with 1 interlock
Discrete output, 16 points, with 3 interlocks
Discrete output, 16 points, with 3 interlocks
