■ Detected Address List (0xF040)
The address of all connected I/O modules are stored in object 0xF040.
The Sub-index numbers are same as the module addresses.
The address of module not installed, the Sub-index is 0. (Refer to the Table 15.)
Table 15: Object 0xF040 Configuration
INDEX SUB-INDEX
0
1
0xF040 2
:
32
■ Device Type (0x1000)
The device type of slave is stored in object 0x1000.
R8 series are compatible with Modular Device Profile (MDP). The device type is 5001. (Refer to the Table 16.)
Table 16: Object 0x1000 Configuration
INDEX DATA TYPE
0x1000 UINT32
■ Manufacturer Device Name (0x1008)
The device name of slave is stored in object 0x1008 in String form. (Refer to the Table 17.)
Table 17: Object 0x1008 Configuration
INDEX DATA TYPE
0x1008 STRING
■ Manufacturer Hardware Version (0x1009)
The hardware device version of slave is stored in object 0x1009 in String form. The format of version is "n.nn." (Refer to the
Table 18.)
Table 18: Object 0x1009 Configuration
INDEX DATA TYPE
0x1009 STRING
■ Manufacturer Software Version (0x100A)
The software version of slave is stored in object 0x100A in String form. The format of version is "n.nn." (Refer to the Table 19.)
Table 19: Object 0x100A Configuration
INDEX DATA TYPE
0x100A STRING
DATA TYPE BIT
UINT8 8
UINT16 32
UINT16 32
: :
UINT16 32
BIT ACCESS VALUE
32 RO 5001
BIT ACCESS VALUE
- RO R8-NECT1
BIT ACCESS VALUE
32 RO n.nn
BIT ACCESS VALUE
32 RO n.nn
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
ACCESS VALUE CONTENT
RO 32 Number of items
RO 0 to 32
RO 0 to 32
Module address or 0
: :
RO 0 to 32
CONTENT
Device type: 5001
CONTENT
Device name
CONTENT
Hardware version
CONTENT
Software version
