5.7.1 Related UD70 parameters
_
Q20%.5
Set at 1 for the current absolute positions of the feedback and reference
encoders to be entered in _Q21% and _Q22% when the Freeze input is
activated.
_Q20%.5 is reset to zero when the values have been entered.
_
Q21%
Units
Range
Reset
_
Q22%
Units
Range
Reset
5.8

Delay times

Delay from input to output (main or second encoder)
when operating in quadrature AB
Delay from Z input to Z output (main or second encoder)
Delay from Freeze input signal to storing of the position
information
Difference in delay between storing the position information from
the main encoder and the position information from the second
encoder
18
Feedback-encoder freeze value
Encoder lines
31 31
-2 to 2
H = S/V S = N/A
Reference-encoder freeze value
Encoder lines
31 31
-2 to 2
H = S/V S = N/A
Function
www.controltechniques.com
Control word (bit 5)
P = N/A
P = N/A
Delay time
1.5µs
1.5µs
2µs
250ns
