4.2

Functions of the terminals

All the I/O conforms to RS EIA485.
Terminal
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
10
Quadrature channel A input (default) or
F (frequency) input
Quadrature channel A\ input (default) or
F\ (frequency\) input
0V
Quadrature channel B input (default) or
D (direction) input
Quadrature channel B\ input (default) or
D\ (direction\) input
0V
Marker pulse Z input
Marker pulse Z \ input
0V
Quadrature channel A output (default) or
F (frequency) output
Quadrature channel A\ output (default) or
F\ (frequency\) output
0V
Quadrature channel B output (default) or
D (direction) output
Quadrature channel B\ output or
D\ (direction\) output
Marker channel Z output (default) or
Freeze input (see Note on page 11)
Marker channel Z\ output (default) or
Freeze\ input (see Note on page 11)
