5.3

Output speed-reference

Reference output: From the UD51 to another drive or a controller
Main feedback: Quadrature encoder connected to the 15-way D-type
connector in the drive
The UD51 can be used to supply a speed reference signal to another drive or
to a controller
Signal format can be either quadrature AB or frequency and direction (F/D).
Refer to Menus 3 and 16.
UD51 User Guide
Issue Number: 5
Figure 5-2
Output to another
Drive or to a
controller
Main feedback
encoder
