Making Connections

4.1

Locations of the terminals

Figure 2 Location of the plug-in terminal block on the UD55
4.2

Functions of the terminals

Terminal
40
41
42 to 55
UD55 User Guide
Issue code: 55nu3
Function
To enable the save function, terminals 40 and 41 should be directly
connected together
No connection
