4.2

Functions of the terminals

Terminal
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
8
Function
Simulated-encoder
phase quadrature output A
or frequency output F
(EIA485 serial link)
Simulated-encoder
phase quadrature output A\
or frequency output F\
(EIA485 serial link)
0V
Simulated-encoder
phase quadrature output B
or frequency output D
(EIA485 serial link)
Simulated-encoder
phase quadrature output B\
or frequency output D\
(EIA485 serial link)
0V
Marker pulse Z output
Marker pulse Z \ output
coil input (low)
SIN
coil input (high)
SIN
coil input (low)
COS
coil input (high)
COS
Excitation output (high)
Excitation output (low)
0V
0V
UD53 User Guide
Issue code: 53nu3
