Technical Specifications

This section provides important technical specifications related to the device.
5.1

General specifications

Insulation
Overvoltage category
5.2

Chassis Specifications

Power Consumption
5.3

Power Supply Specifications

Note
When determining cable lengths, make sure the nominal input voltage for the power
supply is provided at the power source.
Supply Type
a
Power consumption varies based on the device configuration.
b
(T) denotes time-delay fuse.
RUGGEDCOM RX1536
Equipment Manual, 10/2023, C79000-G8976-1488-07
13 W
Input Range
Power
Min
88 VDC
HI
85 VAC
88 VDC
HIP
85 VAC
24
13 VDC
24P
48
36 VDC
48P
12
9 VDC
12P
Class I
OVC II
Internal
Fuse Rating
Max
300 VDC
3.15 A(T)
264 VAC
300 VDC
3.15 A(T)
264 VAC
36 VDC 10 A(T)
72 VDC 3.15 A(T)
15 VDC 12 A
Maximum
Power
a
Consumption
b
65 W
for 1 minute
b
65 W
b
63.5 W
for 1 minute
b
60 W
1500 VAC or
67 W
for 1 minute
5
Insulation
2800 VDC
1500 VDC
2121 VDC
33
